48
Table 25 — Alarm Service Configuration
*0 = Disable
1 = Enable.
†255 disables realarming.
NOTE: Alarm retry time (in the event an alarm is not acknowledged)
is fixed at 5 minutes.
Table 26 — Status Display
*The text used for Mode shall be one of the following:
Off, Occ Cool, Occ Heat, Fan Only, UnocCool, UnocHeat, Warm-Up, Free Cool.
†The text used for Fan Status shall be one of the following:
Off, Low, Medium, High.
**0 =Off, High, or Clean 1 =On, Low, or Dirty.
NOTE: The presence of override limits indicates that the point is forcible, all others are read
only.
DESCRIPTION POINT NAME STATUS / UNITS RANGE DEFAULT
Alarm Routing Control ALRMCNT xxxxxxxx 0 - 1* 11010000
Realarm Time REALARM xxx min 1-255† 255
Cntrl Temp Hys xx.x ^F
Supply Air Temperature SPTHYS 1.0 - 20.0 5.0
Lo Lim LOWLIM xxx.x °F –40.0 - 245.0 45.0
Hi Lim HIGHLIM xxx.x °F –40.0 - 245.0 150.0
Mixed Air Temperature
Lo Lim LOWLIM xxx.x °F –40.0 - 245.0 40.0
Hi Lim HIGHLIM xxx.x °F –40.0 - 245.0 120.0
Relative Humidity
Lo Lim LOWLIM xxx.x %RH 0.0 - 100.0 30.0
Hi Lim HIGHLIM xxx.x %RH 0.0 - 100.0 70.0
Outdoor Air CFM
Lo Lim LOWLIM xxxx.x CFM 0.0 - 5000.0 0.0
Hi Lim HIGHLIM xxxx.x CFM 5000 - 5000 800.0
Air Quality
Lo Lim LOWLIM xxxx.x 0.0 - 5000.0 0.0
Hi Lim HIGHLIM xxxx.x 0.0 - 5000.0 800.0
Outdoor Air Temperature
Lo Lim LOWLIM xxx.x °F –40.0 - 245.0 40.0
Hi Lim HIGHLIM xxx.x °F –40.0 - 245.0 140.0
DESCRIPTION POINT NAME STATUS / UNITS
OVERRIDE
LIMITS
Desired Mode MODE xxxxxx ASCII*
Equipment Status ALARM Norm/Alarm
Controlling Temperature SPT xxx.x °F –40.0 - 245.0
Space Temperature RAT xxx.x °F –40.0 - 245.0
Supply Air Temperature SAT xxx.x °F –40.0 - 245.0
Mixed Air Temperature MAT xxx.x °F –40.0 - 245.0
Outdoor-Air Temperature OATE MP xxx.x °F –40.0 - 245.0
Fan Relay SF Off/On0-1**
Fan Status FANSTAT xxxxxx ASCII†
Remote Start REMOTE Off/On0-1**
Outdoor Air Enthalpy ENT High/Low 0 - 1**
Cooling Capacity CCAP xxx.x %
Heating Capacity HCAP xxx.x %
Outdoor Air cfm OACFM xxxx.x CFM 0.0 - 5000.0
MAD Capacity 0.0 - 100.0 MIXDCAP xxx.x % 0.0 - 100.0
Filter Status FLTSTAT Clean/Dirty 0 - 1**
Air Quality (PPM) AQ xxxx.x 0.0 - 5000.0
Relative Humidity RH xxx.x %RH 0.0 - 100.0
Fire Shutdown Norm/Alarm
FS Fire shutdown
Coil Freeze Detection CFD Norm/Alarm 0 - 1**
Changeover Switch Input CHANGOVR Heat/Cool 0 - 1**
Spare Discrete Input DI0 Off/On0-1**
Spare Analog Input AI0 xx.x Volts 0.0 - 10.0
Mixed Air Damper 1 MIXD1 Off/On0-1**
Mixed Air Damper 2 MIXD2 Off/On0-1**
Cooling 1 CCV1 Off/On0-1**
Cooling 2 CCV2 Off/On0-1**
Heating 1 HCV1 Off/On0-1**
Heating 2 HCV2 Off/On0-1**
Heating Enable Output HEATING Off/On0-1**
Cooling Enable Output COOLING Off/On0-1**
