Table 27 — CCN Configuration
*0 = Disable or No 1 = Enable or Yes
†Value below 65 (i.e., min value/default) disables global occupancy from CCN.
Table 28 — Set Point Configuration
Table 29 — Maintenance
†0 =Off 1 =On
NOTE: The presence of override limits indicates that the parameter is forcible;
all others are read only except those marked (*) which cannot be forced or read from CCN.
DESCRIPTION POINT STATUS / UNITS RANGE DEFAULT
Warm-Up Temp Check WARMENAB Disable/Enable 0 - 1* Enable
Unoccupied Fan Cycling FAN_CYCL Disable/Enable 0 - 1* Disable
Unoccupied Free Cooling NTEN Disable/Enable 0 - 1* Enable
Free Cooling Lock-out NTLO xx.x °F 35 - 80 50.0
DXOutdoor Air Lock-out DXLO xxx.x °F –40 - 65 60.0
Max Offset Adjustment LIMT xx.x ^F0-200.0
Air Quality Control AQEN Disable/Enable 0 - 1* Disable
High Humidity Limit HIHUM xxx.x %RH 0 - 100 100.0
Local RH Sensor RHSENS No/Yes 0 - 1* No
Reheat REHEAT Disable/Enable 0 - 1* Disable
Occ Schd OCCSCHED xx 64 - 99† 64
Tmd Ovr Hrs TIMOVRID x hours 0 - 4 0
Linkage Thermostat
Cool Strt Bias (min/deg)KCOOLxx xx 0-60 10
Heat Strt Bias (min/deg)KHEAT xx min 0 - 60 10
DESCRIPTION POINT STATUS / UNITS RANGE DEFAULT
Setpoint
Oc Heat SP OHSP xx.x °F 40 - 90 70.0
Oc Cool SP OCSP xx.x °F 45 - 99 75.0
Unoc Heat SP UHSP xx.x °F 40 - 90 55.0
Unoc Cool SP UCSP xx.x °F 45 - 99 90.0
Cycle III Damper Setpt C3DSP xx.x °F 40 - 90 55.0
Economizer Lock-Out Temp ELOSP xx.x °F 40 - 90 63.0
Ventilation Setpoint OASP xxxx.x CFM 100 - 5000 200.0
AQ Setpoint (PPM) AQSP xxxx.x 0 - 5000 650.0
DESCRIPTION POINT STATUS / UNITS OVERRIDE LIMITS
Occupied OCCSTAT No/Yes
Linkage in Effect DAVCL No/Yes
Tmd Ovr in Effect TIMOV* No/Yes
Heat Master Reference HCMRxxx.x°F
Heat Submaster Reference HCSR xxx.x °F 35.0 to 140.0
Cool Master Reference CCMRxxx.x°F
Cool Submaster Reference CCSR xxx.x °F 40.0 to 150.0
MAD Master Reference MIXDMRxxx.x°F
MAD Submaster Reference MIXDSR xxx.x °F 48.0 to 120.0
Cfg MAD Min Position MIXDMDP xxx.x % 0.0 to 100.0
Act MAD Min Position DMPRMIN xxx.x %
Temperature Reset Value RESET xx.x ^F
Cooling in Effect COOLFLAG* No/Yes
Heating in Effect HEATFLAG* No/Yes
Reheat in Effect REHTFLAG* No/Yes
AQ Control in Effect AQFLAG No/Yes
AQ Calc Damper Pos MDPAQ*xxx.x%
Fan Status DI FANDI Off/On
Fan Speed Relay 1 FANSPD1 Off/On0-1†
Fan Speed Relay 2 FANSPD2 Off/On0-1†
Linkage Thermostat Linkage Status LINKSTAT* x
Sup Ele SUPE-ADR* xxx
Sup Bus SUPE-BUS* xxx
Sup Blk # BLOCKNUM*x
Avg Oc Heat SP OCLOSTPT* xx.x °F
Avg Oc Cool SP OCHISTPT* xx.x °F
Avg Unoc Heat SP UNLOSTPT* xx.x °F
Avg Unoc Cool SP UNHISTPT* xx.x °F
Avg Zone Tmp AZT* xx.x °F
Avg Oc Zone Tmp AOZT* xx.x °F
OcStat OCCSTAT* x
