56
1
2
BLOWER SECTION
DAMPER SECTION
COIL SECTION
FILTER DOOR
RETAINER CLIPS
(SEE NOTE 3)
DAMPER SECTION
COIL SECTION
MOTOR
ELECTRICAL
BOX
MOTOR
MOTOR & COUPLING
SETSCREW ACCESS
DISCHARGE AIR
TEMPERATURE SENSOR
OPENING
RETURN AIR
TEMPERATURE
SENSOR OPENING
FRONT
COIL
BAFFLE
Fig. 39 — 40UV,UH Ventilator Coil Section
NOTES:
1. Unit shown in vertical orientation. Drawing
applies to horizontal and vertical units.
2. Not all components shown for clarity.
3. 40UV,UH125-150, 40UH200 units only.
