55
1
2
3
4
5
7
6
SEE DETAIL A
SEE DETAIL A
6
SEE NOTE 4
BOTTOM VIEW
DETAIL A
Fig. 38 — 40UV,UH Ventilator Inboard Bearing (40UV,UH150 Only)
NOTES:
1. Not all components shown for clarity.
2. This drawing applies to 1500 cfm units only.
3. Remove shaft, motor, and coupling prior to
bearing removal.
4. Refer to Fig. 36 and 43 for motor-coupling and
coupling-shaft tolerances.
