42D ELECTRIC HEATER DATA
LEGEND
FLA — Full Load Amps
NOTES:
1. All heaters are single-stage and single-phase.
2. In all units using over 48 amps, the heating elements are sub-
divided and protected. Additional cost is incurred because of
added components.
3. A separate power source is required for motor and heaters except
when motors and heaters of same voltage are ordered in conjunc-
tion with a single power source wiring option. This option, which
meets NEC (National Electric Code) requirements, consists of a
factory-furnished and installed junction box and fuse for 6.25 amp
(max) fan and control circuit connection to a single power source.
Power supply circuit to unit must be field furnished and installed in
accordance with applicable codes.
42DA PSC MOTOR DATA
*Total motor amps and watts shown for units with 2 motors (size 12 through 20).
NOTES:
1. Motor nameplate amps may vary.
2. Fan coil units comply with ETL, Canadian Standards Association
(CSA), and ETL of Canada standards.
HEATER
VOLTAGE
HEATER kW
2.0 3.0 4.0 5.0 6.0 7.0 8.0 9.0 10.0 12.0 14.0
FLA
120 16.725.0—————————
208 9.6 14.4 19.2 24.0 28.8 33.7 38.5 43.3 48.1 57.7 67.3
240 8.3 12.5 16.7 20.8 25.0 29.2 33.3 37.5 41.7 50.0 58.3
277 7.2 10.8 14.4 18.0 21.7 25.3 28.9 32.5 36.1 43.3 50.5
V-Ph-Hz
FAN
SPEED
FAN
SPEED
(RPM)
UNIT SIZE
06 08 10 12*
Nominal
Hp
Watts Amps
Nominal
Hp
Watts Amps
Nominal
Hp
Watts Amps
Nominal
Hp
Watts Amps
115-1-60
H 1200
1
/
8
280 2.70
1
/
5
330 3.10
1
/
4
470 5.60
1
/
8
(2)
550 5.30
M
980 200 2.00 225 2.25 360 3.70 305 2.92
L
790 140 1.50 135 1.44 240 2.60 205 1.93
208/230-1-60
H 1200
1
/
10
240 1.10
1
/
5
420 1.80
1
/
4
430 2.00
1
/
5
(2)
450 2.10
M
980 175 0.74 280 1.26 260 1.20 325 1.45
L
790 110 0.50 155 0.73 165 0.80 215 1.00
277-1-60
H
1200
1
/
5
275 1.15
1
/
5
275 1.21
1
/
4
425 1.62
1
/
5
(2)
550 2.40
M
980 175 0.69 175 0.69 260 1.04 355 1.38
L
790 90 0.33 90 0.34 155 0.65 175 0.67
V-Ph-Hz
FAN
SPEED
FAN
SPEED
(RPM)
UNIT SIZE
14* 16* 18* 20*
Nominal
Hp
Watts Amps
Nominal
Hp
Watts Amps
Nominal
Hp
Watts Amps
Nominal
Hp
Watts Amps
115-1-60
H 1200
1
/
5
(2)
650 6.40
1
/
4
(2)
900 8.80
1
/
4
(2)
1180 11.80
1
/
4
(2)
1180 11.80
M
980 440 4.60 705 6.90 770 8.30 770 8.30
L
790 280 3.00 430 4.20 460 5.30 460 5.30
208/230-1-60
H 1200
1
/
5
(2)
465 2.10
1
/
5
(2)
740 3.60
1
/
4
(2)
925 4.10
1
/
4
(2)
925 4.10
M
980 325 1.45 360 1.80 5.45 2.48 545 2.48
L
790 220 1.00 220 1.20 330 1.60 330 1.60
277-1-60
H 1200
1
/
4
(2)
735 2.70
1
/
4
(2)
940 3.60
1
/
4
(2)
980 3.72
1
/
4
(2)
980 3.72
M
980 510 1.90 560 2.20 550 2.20 550 2.20
L
790 330 1.30 335 1.40 320 1.40 320 1.40
