113
TOP
FRONT RIGHT
22
(559)
24
(610)
24
(610)
24
(610)
3 (76) 3 (76)
1-1/4 (32)
11
(279)
1-1/4 (32)
30
(762)
16
(406)
22
(559)
4
(102)
1
(25)
22
(559)
1
(25)
1-1/4 (32)
16
(406)
4
(102)
42SM OPTIONAL SUPPLY PLENUM
NOTES:
1. Plenum box adds 22-in. (559 mm) to unit height, adds 26 lb (11.8 kg) to unit weight, and is factory
installed.
2.
1
/
4
-in. closed cell insulation is standard for the plenum box.
3. Side supply is 22-in. (559 mm) x 16-in. (406 mm) on all four sides.
4. Top supply is 24-in. (610 mm) x 11-in. (279 mm) which matches unit top ducted discharge.
5. All dimensions are in inches (mm).
a42-4270
a42-4270
Accessory dimensions
