Carrier 42C Series User Manual

69
42VA FURRED-IN VERTICAL UNIT
TOP VIEW
SUPPLY AIR OPENING
ACCESS PANEL
REMOVABLE FRONT
DUCT COLLAR
1" (25) SUPPLY
3/4" (19) MPT CONNECTION
DRAIN PAN WITH
PLASTIC AUXILIARY 7X7
RETURN AIR OPENING
SUPPLY
AIR
2
(51)
5
(127)
2-1/4
(57)
A
6-1/2
(165)
B
9-1/4
(235)
4
(102)
11-3/4
(298)
25
(635)
3-3/4
(95) *
3-3/4
(95) *
D
MOUNTING HOLES RIGHT SIDE VIEW
AIR
RETURN
2-7/8
(73)
C
5-1/2
(140)
STD.
OPTIONAL
CONTROL
BOX SHOWN
(STD IS
2X4 J-BOX)
2
(51)
DRAIN
TROUGH
SUPPLY &
WATER
RETURN
CONNECTIONS
AIR VENT
9 1/4
(235)
1
(25)
8-1/4
(210)
1" (25)
FILTER
14-1/2
(368)
16-1/8
(410)
1/2" (13)
MOUNTING
HOLES
(TYP OF 4)
4
(102)
1/2(2X)
(13)
4-1/2
(114)
(DIMENSION FROM
INSIDE CASE LEG)
(DIMENSION FROM
MOUNTING HOLE)
2-1/2
(64)
FRONT VIEW
NOTES:
1. All dimensions are ± 1/4-in. (6).
2. Standard 3-row coil shown.
3. Right hand unit shown, left hand unit is opposite.
4. Dimensions shown in inches (mm).
UNIT
SIZE
DIMENSIONS (in.) QTY/UNIT
UNIT WEIGHT*
(lb)
ABCD
Blower Motor
02 24
3
/
16
22 23 16 1 1 42
03 24
3
/
16
22 23 18 1 1 47
04 34
3
/
16
32 33 26 2 1 57
06 44
3
/
16
42 43 36 2 1 77
08 46
3
/
16
44 45 38 2 1 79
10 60
3
/
16
58 59 52 4 2 108
12 68
3
/
16
66 67 60 4 2 127
*Unit weights are based on dry coils and minimum rows. Weights exclude packaging, valves, and other components.
Base unit dimensions
42V Series Units
