84
ELECTRIC HEATER DATA
LEGEND
FLA — Full Load Amps
NOTE: All heaters are single-stage and single-phase.
42VA,VB, AND VF PSC MOTOR DATA
*Total motor amps and watts shown for units with 2 motors.
NOTES:
1. Motor nameplate amps may vary.
2. Fan coil units comply with ETL, Canadian Standards Association (CSA), and
ETL of Canada standards.
HEATER
VOLTAGE
HEATER kW
1.0 1.5 2.0 3.0 4.0 5.0 6.0
FLA
120 8.3 12.5 16.7 25.0 — — —
208 4.8 7.2 9.6 14.4 19.2 — —
240 4.2 6.3 8.3 12.5 16.7 — —
277 3.6 5.4 7.2 10.8 14.4 18.05 21.7
V-Ph-Hz
FAN
SPEED
FAN
SPEED
(RPM)
UNIT SIZE
02 03 04 06
Nominal Hp Watts Amps Nominal Hp Watts Amps Nominal Hp Watts Amps Nominal Hp Watts Amps
115-1-60
H 1200
1
/
40
60 0.39
1
/
30
80 0.69
1
/
12
125 1.20
1
/
6
180 1.94
M 980 50 0.35 60 0.51 85 0.73 140 1.30
L 790 45 0.28 50 0.42 60 0.56 85 0.76
208-1-60
H 1200
1
/
40
70 0.26
1
/
30
95 0.45
1
/
12
115 0.54
1
/
6
145 0.74
M 980 65 0.24 70 0.35 85 0.41 100 0.51
L 790 60 0.22 50 0.24 55 0.26 60 0.31
230-1-60
H 1200
1
/
40
75 0.28
1
/
30
110 0.47
1
/
12
130 0.56
1
/
6
160 0.72
M 980 70 0.26 85 0.36 100 0.43 115 0.51
L 790 65 0.24 60 0.25 60 0.28 70 0.33
277-1-60
H 1200
1
/
40
70 0.16
1
/
30
105 0.52
1
/
12
130 0.57
1
/
6
185 0.68
M 980 60 0.13 85 0.37 105 0.41 135 0.49
L 790 55 0.10 55 0.21 65 0.24 110 0.41
V-Ph-Hz
FAN
SPEED
FAN
SPEED
UNIT SIZE
08 10* 12*
Nominal Hp Watts Amps Nominal Hp Watts Amps Nominal Hp Watts Amps
115-1-60
H 1200
1
/
6
195 1.92
1
/
12
(2)
260 2.54
1
/
6
(2)
335 3.75
M 980 150 1.35 175 1.54 255 2.43
L 790 80 0.72 135 1.18 160 1.47
208-1-60
H 1200
1
/
6
155 0.79
1
/
12
(2)
225 1.06
1
/
6
(2)
270 1.36
M 980 100 0.52 175 0.81 190 0.97
L 790 55 0.30 110 0.51 120 0.62
230-1-60
H 1200
1
/
6
170 0.80
1
/
12
(2)
260 1.10
1
/
6
(2)
295 1.37
M 980 115 0.54 200 0.84 210 0.97
L 790 65 0.33 130 0.54 140 0.66
H 1200
1
/
6
195 0.74
1
/
12
(2)
275 1.14 295 1.37
277-1-60 M 980 135 0.53 215 0.80
1
/
6
(2) 250 0.91
L 790 110 0.43 140 0.47 215 0.79
Electrical data
