AIR DELIVERY (CFM)
NOTE: Ratings based on standard cfm at sea level, 70 F entering dry
coil. Ratings include factory-installed filter and/or grille, where
applicable.
UNIT SIZE COIL
CFM AT 0.0 ESP FOR FAN SPEED HIGH SPEED CFM AT ESP INDICATED
LOW MED HIGH 0.10 0.20 0.25 0.30 0.40 0.50 0.60
42DA
06
3-Row 545 645 800 740 680 650
620 560 470 330
4-Row 530 360 780 720 660 630
600 540 430 260
6-Row 505 595 740 680 620 590
560 470 330 —
08
3-Row 645 885 1080 1010 940 910
870 800 710 590
4-Row 630 870 1060 990 920 890
850 770 680 540
6-Row 600 830 1010 940 870 840
800 710 590 —
10
3-Row 825 1045 1280 1260 1240 1190
1130 1010 910 640
4-Row 805 1020 1250 1230 1210 1160
1100 970 840 700
6-Row 765 975 1190 1170 1140 1090
1030 890 720 —
12
3-Row 945 1125 1450 1360 1270 1220
1180 1090 990 850
4-Row 925 1100 1420 1330 1240 1200
1150 1060 950 790
6-Row 885 1055 1360 1270 1180 1130
1090 990 850 —
14
3-Row 890 1405 1875 1730 1590 1520
1450 1310 1170 920
4-Row 860 1355 1810 1680 1550 1490
1420 1270 1110 890
6-Row 820 1300 1730 1590 1450 1380
1310 1170 970 —
16
3-Row 900 1420 2080 1940 1800 1730
1660 1510 1350 1110
4-Row 875 1385 2030 1890 1750 1680
1610 1460 1280 1000
6-Row 845 1335 1960 1810 1660 1590
1510 1350 1110 —
18
3-Row 1160 1720 2630 2570 2485 2415
2340 2170 1945 —
4-Row 1145 1685 2445 2380 2285 2215
2145 1985 1770 —
6-Row 1115 1615 2075 1990 1885 1820
1755 1615 1425 —
20
3-Row 1225 1860 2780 2700 2605 2545
2470 2310 2120 —
4-Row 1210 1825 2595 2510 2405 2345
2275 2125 1950 —
6-Row 1180 1755 2225 2120 2010 1945
1885 1755 1600 —
42DC,
DD,DE
06
3-Row 535 630 780 710 640 600
570 500 410 280
4-Row 520 610 760 690 620 580
550 470 380 230
6-Row 485 570 710 640 570 540
500 410 280 —
08
3-Row 590 810 990 920 850 820
780 700 590 430
4-Row 575 795 970 900 830 790
760 670 550 350
6-Row 560 770 940 860 780 740
700 590 430 —
10
3-Row 755 955 1170 1140 1100 1040
990 910 810 700
4-Row 735 930 1140 1110 1070 1010
960 860 760 660
6-Row 690 875 1070 1030 990 930
880 760 620 —
12
3-Row 1040 1240 1600 1480 1360 1300
1240 1120 980 780
4-Row 1035 1235 1590 1460 1330 1270
1200 1070 920 700
6-Row 965 1145 1480 1360 1240 1180
1120 980 780 —
14
3-Row 1290 1770 1940 1795 1660 1595
1525 1390 1280 1085
4-Row 1260 1710 1880 1740 1610 1550
1485 1350 1210 1015
6-Row 1200 1590 1745 1625 1510 1455
1400 1265 1065 —
16
3-Row 1105 1710 2380 2230 2100 2015
1945 1785 1640 —
4-Row 1075 1650 2320 2175 2050 1970
1905 1745 1570 —
6-Row 1015 1530 2180 2060 1950 1875
1820 1660 1425 —
18
3-Row 1105 1675 2515 2450 2355 2275
2185 2045 1850 —
4-Row 1090 1640 2355 2260 2155 2075
1990 1860 1657 —
6-Row 1060 1570 1990 1870 1755 1680
1600 1490 1330 —
20
3-Row 1170 1815 2690 2580 2475 2405
2315 2185 2025 —
4-Row 1155 1780 2505 2390 2275 2205
2120 2000 1855 —
6-Row 1125 1710 2140 2000 1880 1810
1730 1630 1505 —
Performance data
