The 42V Series fan coil units are certified in compliance
with the Air-Conditioning, Heating and Refrigeration Insti-
tute (AHRI) Industry Standard 440 for room fan coil units.
Approved standard ratings are tabulated below:
AHRI APPROVED STANDARD RATINGS*
LEGEND
*Ratings based on motor at high fan speed, standard air and dry coil oper-
ation, 10° F water temperature rise; entering-air temperature 67 F wb;
80 F db; entering water temperature 45 F.
†Motor type permanent split capacitor operating at 115-1-60 voltage.
**Shaded pole motor.
UNIT
UNIT
SIZE
COIL
ROWS
NOMINAL
CFM
GPM
COOLING CAPACITY
POWER
INPUT (WATTS)†
Total
MBtuh
Sensible
MBtuh
42VA,VB,VF
02
3
200 1.0 6.9 4.7 80
03 300 1.5 8.1 5.9 110
04 400 2.4 11.6 8.8 135
06 600 3.0 18.7 13.4 190
08 800 4.0 20.8 14.4 200
10 1000 4.8 31.7 21.1 275
12 1200 5.3 34.1 23.9 355
02
4
200 — — — —
03 300 2.0 9.2 6.5 110
04 400 2.7 12.7 9.1 135
06 600 3.8 20.6 14.2 190
08 800 4.2 21.7 14.3 200
10 1000 5.9 30.7 19.9 275
12 1200 7.8 38.9 25.6 350
42VG
01
2
150 0.6 2.1 1.6 135**
03 300 1.5 5.2 4.7 270**
42VC,VE
02
2
200 1.2 5.1 3.6 68
03 300 2.0 8.6 6.7 135
04 400 2.6 12.3 8.3 150
06 600 3.6 18.3 13.2 260
02
3
200 1.3 5.5 3.8 68
03 300 2.4 10.9 7.1 130
04 400 3.0 13.4 8.8 145
06 600 4.1 21.1 14.6 250
GPM — Gallons per minute
MBtuh — Capacity (Btuh in thousands)
AHRI capacity ratings
