127
42SG, SH, SJ, SU ECM MOTOR DATA
42S ELECTRIC HEATER DATA
LEGEND
FLA — Full Load Amps
NOTES:
1. All heaters are single stage and single-phase. Two-stage heaters
may be available with a special request.
2. In all units using over 48 amps, the heating elements are subdi-
vided and protected. Additional cost is incurred because of added
components. Each circuit of the electric heater coil has an auto-
matic reset thermal cutout with back-up high limit control and oper-
ating contactor.
3. Electric heater and motor voltage must be the same and need to
be ordered in conjunction with a single power source wiring option.
This option, which meets NEC (National Electric Code) require-
ments, consists of a factory-furnished and installed junction box
and fuse for 6.25 amp (max) fan and control circuit connection to a
single power source. All units with electric heat must include a
fused service switch. Power supply circuit to unit must be field fur-
nished and installed in accordance with applicable codes.
4. Fan coil units comply with ETL, Canadian Standards Association
(CSA), and ETL of Canada standards.
SIZE NOMINAL HP
AMPS
120V 208V 230V 277V
42S*03
1
/
6
2.4 1.6 1.5 1.042S*04
1
/
6
42S*06
1
/
6
42S*08
1
/
2
8.44 43.342S*10
1
/
2
42S*12
1
/
2
HEATER
VOLTAGE
HEATER kW
1.0 1.5 2.0 3.0 4.0 5.0 6.0 8.0 10.0 12.0
FLA
120 8.3 12.5 16.7 25.0 — — — — — —
208 4.8 7.2 9.6 14.4 19.2 24.0 28.8 38.5 — —
240 4.2 6.2 8.3 12.5 16.7 20.8 25.0 33.3 45.5 —
277 3.6 5.4 7.2 10.8 14.4 18.0 21.7 28.9 36.1 43.3
