46
DOUBLE DEFLECTION
SUPPLY AIR GRILLE
C
B
C
RESILIENT MOUNTING
GROMMETS WITH 3/8" (10)
DIA HOLE (TYP. OF 4)
Ø7/8" (22) KNOCKOUT
(TYP. OF 2)
Ø1-1/2" KNOCKOUT
(TYPE. OF 5)
PARTIAL REAR VIEW
(TYPICAL BOTH SIDES)
2
(51)
CHILLED/HOT WATER
SUPPLY & RETURN
CONNECTIONS
TOP VIEW
CONTACTOR BOX (J-BOX ON
UNITS WITH NO CONTROLS)
3-1/2
(89)
2
(51)
2
(51)
E
A
18
(457)
1" RETURN
DUCT COLLAR &
1" (25) FILTER
OPTIONAL “L” SHAPED
DRIP LIP, SHIPPED LOOSE
FRONT VIEW
REMOVABLE HINGED
RA/ACCESS PANEL
23-1/2
(597)
1" RETURN
DUCT COLLAR
&
1" (25) FILTER
6
(152)
RETURN
AIR
1-1/2
(38)
G
F
SUPPLY
AIR
AIR VENT
7/8" (22) O.D.
CONDENSATE
DRAIN CONNECTION
RIGHT SIDE VIEW
2
(51)
APPROX.
REF.
OPTIONAL
ELECTRIC STRIP
HEATER ELEMENT
42CG HORIZONTAL CABINET WITH DOUBLE DEFLECTOR SUPPLY AIR GRILLE,
DUCT REAR RETURN AND HEATER
A42-4315
NOTES:
1. Right hand unit shown; left hand unit opposite.
2. Internal factory valve package and drains may not align with
cabinet knockouts.
3. All dimensions ±
1
/
4
-in.
4. Cabinet is Arctic White polyester powder coat paint.
UNIT
SIZE
NOM
AIRFLOW
(Cfm)
DIMENSIONS (in.)
DUCTED REAR
RETURN SIZE
(in.)
FILTER SIZE
(in.)
QTY/UNIT
AB CEFG
Blower Motor
02 200 38 17
1
/
8
10
7
/
16
34 5
3
/
4
11 6 x 21
1
/
2
8 x 23
1
/
2
11
03 300 42 21
1
/
2
10
1
/
4
38 5
3
/
4
11 6 x 25
3
/
4
8 x 28 1 1
04 400 48 25
7
/
8
11
1
/
16
44 5
3
/
4
11 6 x 30
1
/
4
8 x 32
1
/
2
21
06 600 53 34
5
/
8
9
3
/
16
49 6
3
/
4
12 6 x 34
1
/
2
8 x 37 2 1
08 800 60 39 10
1
/
2
56 6
3
/
4
12 6 x 39 8 x 41 2 1
10 1000 74 52
1
/
8
10
15
/
16
70 6
3
/
4
12 6 x 52 8 x 54
1
/
2
42
12 1200 82 60
7
/
8
10
9
/
16
78 6
3
/
4
12 6 x 60
3
/
4
8 x 63 4 2
Base unit dimensions (cont)
