56
DISCHARGE AIR GRILLES
*Refer to unit dimensions to size field transitions.
DISCHARGE GRILLES
Unit
Size
Nominal
Airflow
(Cfm)
Recommended Grille
Sizes (in.)
Unit
42C*
02 200 16 x 6
03 300 20 x 6
04 400 26 x 6
06 600 30 x 6
08 800 38 x 6
10 1000 52 x 6
12 1200 60 x 6
INTEGRAL DOUBLE-DEFLECTION GRILLE
FOR HORIZONTAL UNITS
(Installed on 42CG Unit as Shown)
A42-4117
Accessory dimensions (cont)
42C Series Units
