78
13
42VE CABINET LOWBOY UNIT WITH ELECTRIC HEAT
*Unit weights are based on dry coils and minimum rows. Weights exclude packaging, valves, and other components.
UNIT SIZE
NOM
AIRFLOW
(Cfm)
DIMENSIONS (in.) QTY/UNIT
FACE AREA
(sq ft)
UNIT
WEIGHT*
(lb)
ABCD
Blower Motor
02 200 41 22 3
3
/
4
17 2 1 1.18 72
03 300 46 27 4 21
1
/
2
2 1 1.53 100
04 400 54 35 3
5
/
8
30
1
/
4
2 1 2.08 108
06 600 68 49 4
1
/
16
43
3
/
8
4 2 3.06 154
LEGEND
1— Fan Switch, 3-Speed, behind Access Door
2— Electrical Sheath Heater Element
3— Stamped Supply Grille
4— Supply Conn,
5
/
8
-in. OD
5— Return Conn,
5
/
8
-in. OD
6— Stamped Return Grille
7— Filter
8— Air Vent,
1
/
8
-in. MPT
9— Front Panel Fastener
10 — Optional Valve Package (inside cabinet)
11 — Drain Pan, Auxiliary, with
3
/
4
-in. MPT
Drain Connection
12 — Return Air Grille
13 — Drain Pan
NOTES:
1. Right hand unit shown; left hand unit opposite. Coil connection
locations are ±
5
/
8
-inches.
2. Unit sizes 02 through 04 have one motor, 2 blowers; size 06 has
2 motors, 4 blowers.
3. Cabinet has an Arctic White baked finish.
4. Height increases by 2 in. with electric heat.
5. Standard 2-row coil shown.
6. Not shown:
1
/
2
-in. fiberglass insulation on inside of casing,
closed cell foam on main drain pan.
7. See 42VC-203-1 for optional coil connections.
8. Valve package is factory-installed inside the cabinet when
ordered with the unit (based on component size).
9. Dimensions shown in inches (mm).
A42-4115
Base unit dimensions (cont)
