Carrier 48HC D17 Series - Cooling Charging Charts - 15 Ton; Fig. 25 - Cooling Charging Chart-15 Ton (Circuit A); Fig. 26 - Cooling Charging Chart-15 Ton (Circuit B)

22
COOLING CHARGING CHARTS
°
°
F 35 40 45 50 55 60 65 70 75 80 85 90 95 100
C 1.7 4.4 7.2 10.0 12.8 15.6 18.3 21.1 23.9 26.7 29.4 32.2 35.0 37.8
185.0
175.0
165.0
155.0
145.0
135.0
125.0
115.0
105.0
95.0
85.0
75.0
Suction Pressure (psig)
Suction Temperature
50HE501045-C
115F / 46.1C
105F / 40.6C
95F / 35.0C
85F / 29.4C
75F / 23.9C
65F / 18.3C
55F / 12.8C
45F / 7.2C
C12227
Fig. 25 -- Cooling Charging Chart--15 Ton (Circuit A)
°
°
F 35 40 45 50 55 60 65 70 75 80 85 90 95 100
C 1.7 4.4 7.2 10.0 12.8 15.6 18.3 21.1 23.9 26.7 29.4 32.2 35.0 37.8
185.0
175.0
165.0
155.0
145.0
135.0
125.0
115.0
105.0
95.0
85.0
75.0
Suction Pressure (psig)
Suction Temperature
50HE501046-C
115F / 46.1C
105F / 40.6C
95F / 35.0C
85F / 29.4C
75F / 23.9C
65F / 18.3C
55F / 12.8C
45F / 7.2C
C12228
Fig. 26 -- Cooling Charging Chart--15 Ton (Circuit B)
48HC
