medium pressure switch MPS closes the inducer motor RPM is
noted by the furnace control CPU. The RPM is used to evaluate
vent system resistance. This evaluation is then used to determine
the required RPM necessary to operate the inducer motor at
maximum-heat. The blower motor BLWM will transition to
maximum-heat airflow five seconds after the furnace control CPU
switches from a low range input to maximum-heat. As the inducer
RPM increases, the high pressure switch HPS should close.
Switching from Medium Range Input to Maximum-Heat - If the
furnace control CPU switches from medium range input to
maximum-heat, the furnace control CPU will increase the inducer
motor speed to the maximum-heat inducer motor RPM. The blower
motor BLWM will transition to the maximum-heat airflow five
seconds after the furnace control CPU switches from a medium
range input to maximum-heat. As the inducer RPM increases, the
high pressure switch HPS should close.
8. Blower-OFF Delay - When the thermostat is satisfied, the R to W
circuit is opened, de-energizing the gas valve GV (pin 5), stopping
gas flow to the burners, and humidifier terminal HUM. The inducer
motor IDM will remain energized for a 15-second post-purge
period. The blower motor BLWM and air cleaner terminal EAC-1
will remain energized at minimum-heat airflow or transition to
minimum-heat airflow for 90, 120, 150, or 180 seconds (depending
on selection at blower-OFF delay switches). The furnace control
CPU is factory-set for a 120-second blower- OFF delay.
Two-Stage Thermostat and Modulating Heating
(Adaptive Mode) Htt = 1St
Operation of Modulating Heating with a two-stage thermostat and
Heating Thermostat Type (Htt) set to (1st) is the same as with a
single-stage thermostat, EXCEPT for the following:
If the two-stage thermostat R-W2 circuit closes along with the R to
W/W1 circuit, while the furnace is operating at any capacity less than
maximum, the furnace will switch to the maximum heating capacity. At
this point, the furnace control heating algorithm is overridden and the
two-stage thermostat takes control of staging until BOTH R to W/W1
and R to W2 circuits are opened.
The furnace will transition back to the lower heating capacity if the
two-stage thermostat opens the R-W2 circuit, but leaves R to W/W1
circuit closed. The furnace control will continue to follow the commands
from the two-stage thermostat for W/W1 and W2, until the R to W/W1
circuit is opened.
After the two-stage thermostat opens both the R to W/W1 and R to W2
circuits, the adaptive algorithm will set the beginning capacity of the
next heating cycle to the same value as the heating cycle that most
recently completed.
Two-Stage Thermostat and Two-Stage
Minimum/Maximum Heating Htt = 2St-LHt
See Fig. 38 for thermostat connections.
NOTE: In this mode, Heating Thermostat Type (Htt) set to (2st-LHt) to
select the minimum-heat only operation mode in response to closing the
thermostat R to W1 circuit. Closing the thermostat R to W1-and-W2
circuits always causes maximum-heat operation, regardless of the setting
of the minimum-heat only switch.
The furnace will start up in either intermediate-, or maximum-heat. The
furnace will operate in minimum-heat after starting and operating for 1
minute at intermediate-heat before transitioning to minimum-heat.
The wall thermostat ”calls for heat”, closing the R to W1 circuit for
minimum-heat or closing the R to W1-and-W2 circuits for
maximum-heat. The furnace control performs a self-check, and verifies
the low, medium and high pressure switch contacts LPS, MPS and HPS
are open, then de-energizes the PSR relay to close the NC contact.
The start up and shut down functions and delays described above apply
to the 2-stage minimum/maximum heating mode as well, except for
switching from maximum- to minimum-heat.
9. Switching from Maximum- to Minimum-Heat - If the thermostat
R to W2 circuit opens, and the R to W1 circuit remains closed, the
furnace control CPU will gradually decrease the inducer motor
speed to the required intermediate-heat RPM. When the inducer
motor IDM reduces pressure sufficiently, the high pressure switch
HPS will open and the gas rate will be changed to
intermediate-heat. The gas valve solenoid GV (pin 5) will remain
energized as long as the low pressure switch LPS remains closed.
When the inducer motor speed gets within 15% of the required
intermediate-heat RPM the furnace control CPU will start a 5
second blower airflow change delay. After the 5 second blower
airflow change delay is completed the blower airflow will transition
to minimum-heat airflow. At this point the furnace control CPU
will energize the PSR relay to open the NC contact and slowly
decrease the inducer motor speed to the required minimum-heat
RPM. When the PSR relay is energized and the NC contact opens
the furnace control CPU will reduce the gas rate to minimum-heat
RPM.
Two-Stage Thermostat and Two-Stage Intermediate/
Maximum Heating Htt = 2St-iHt
See Fig. 38 for thermostat connections
NOTE: In this mode the Heating Thermostat Type (Htt) set to (2st-iHt)
to select the intermediate-heat only operation mode in response to
closing the thermostat R to W1 circuit. Closing the thermostat R to
W1-and-W2 circuits always causes maximum-heat operation, regardless
of the setting of the intermediate-heat only switch.
The wall thermostat ”calls for heat”, closing the R to W1 circuit for
intermediate-heat or closing the R to W1-and-W2 circuits for
maximum-heat. The furnace control performs a self-check, and verifies
the low, medium and high pressure switch contacts LPS, MPS and HPS
are open, then de-energizes the PSR relay to close the NC contact.
The start up and shut down functions and delays described above apply
to the two-stage intermediate/maximum heating mode as well, except for
switching from maximum- to intermediate-heat.
1. Switching from Maximum- to Intermediate-Heat - If the
thermostat R to W2 circuit opens, and the R to W1 circuit remains
closed, the furnace control CPU will gradually decrease the inducer
motor speed to the required intermediate-heat RPM. When the
inducer motor IDM reduces pressure sufficiently, the high pressure
switch HPS will open and the gas rate will be changed to
intermediate-heat. When the inducer motor speed gets within 15%
of the required intermediate-heat RPM the furnace control CPU
will start a 5 second blower airflow change delay. After the 5
second blower airflow change delay is completed the blower
airflow will transition to intermediate-heat airflow.
Cooling Mode
The thermostat “calls for cooling.”
a. Single-Speed Cooling-
See Fig. 38 for thermostat connections
The thermostat closes the R-to-G-and-Y circuits. The R-to- Y
circuit starts the outdoor unit, and the R-to-G-and-Y/Y2 circuits
start the furnace blower motor BLWM on high cooling airflow.
High cooling airflow is based on the high cooling speed (CL2)
selection. The electronic air cleaner terminal EAC-1 is energized
with 115 VAC when the blower motor BLWM is operating.
When the thermostat is satisfied, the R-to-G-and-Y circuits are
opened. The outdoor unit will stop, and the furnace blower motor
BLWM will continue operating at cooling airflow for an
additional (See Fig. 58) 5, 30, or 90 seconds (depending on the
cooling blower-OFF delay (Cod) setting). The furnace CPU is
factory set for a 90 second cooling blower-OFF delay.
