Disconnect the power supply to the cabinet.
Access the raceway (top or bottom mount) by remov-
ing the front panels.
Remove the raceway cover.
1. Terminal board (power to mullion heater).
2. Heated door receptacle.
3. Door switch.
4. Fluorescent light harness.
CABINET RACEWAY / LOWER FRONT PANEL
11
11
22
22
33
33
44
44
MAINTENANCE & REPAIR 47
