ELECTRICAL/REFRIGERATION SPECS. BT30RF-EXPR
Medium Temp., Solid, 1-Door Refrigerator/Freezer
Compressor Tecumseh AE800AT-421-A4
Recommended Operating Temp. Range 35°F to 50°F (2°C to 10°C)
Cabinet Volts 115
Expansion Device Capillary Tube - 8' x .036
Charge Refrig. Type / Oz. / Grams R-134A / 10 / 283.5
SYSTEM COMPONENTS
AMBIENT 70°F / 21.1°C 80°F / 27°C 90°F / 32.5°C
Cavity Temp. (F/C) 37 / 2.7 41 / 5° 40 / 4.5
Suction Pressure (PSIG / Kpa) -3 / -21 3 / -21 1 / 7
Discharge Pressure (PSIG / Kpa) 107 / 738 126 / 869 144 / 993
Compressor Amps 2.1 2.2 2.4
Total Refrigeration Amps 2.4 2.4 2.4
Cabinet Pull Down 70° to 44° - Approx. 2 Hr.
SYSTEM PERFORMANCE
ELECTRICAL/REFRIGERATION SPECIFICATIONS 73
