UNIT COMPARTMENT LAYOUT BT30RF-EXPR
1. Compressor (Explosion Proof)
2. PTC Relay & Overload
(sealed enclosure)
3. Thermostat
4. Thermostat Adjustment (enclosed)
5. Liquid Line Process Tube
(high side)
6. Compressor Process Tube
(high side)
7. Cold Wall Process Tube
(low side)
8. Hot Gas Perimeter Loop
9. Condenser Inlet and Outlet
10. Capillary Tube Inlet
22
55
44
11
8899
66
1100
77
33
74 UNIT COMPARTMENT LAYOUT
