DIMENSIONS AND WEIGHTS OF DUCTED INDOOR UNITS
6.2 Ducted Indoor Units - High Static Pressure Sizes 42K, 48K, 60K
- The refrigerant piping connections and control box are located on the right hand side
of the indoor unit when facing supply air side of the unit.
- The indoor unit should be installed for horizontal supply air flow.
- The indoor unit should be suspended horizontally using the factory provided holes located
at the topside flanges of the indoor unit.
Weight
Model
Kg
42KDHT42N-718T
56
42KDHT48N-718T
56
42KDHT60N-718T
56
Dimensions ( mm )
Number
Name
Description
1
Suction pipe connection
---
2
Liquid pipe connection
---
3
Drain pipe connection
OD Ø 25 ID Ø 20
4
Drain pipe connection
Using drain pump (optional)
5
Power supply connection
---
6
Supply air flange
---
7
Aluminium mesh air filter
10 mm thick
Kg
1200
Ø 5
2- Ø 3.2
1000 ( Supply air duct flange )
10
10
900
270
14
29
550
325
925
1145 ( Return air duct flange )
1236 ( Suspension position )
495 ( suspension position)
29
14
380
6
6
14
29
130
1
2
3
4
5
170
14
29
7
Ø 5
2- Ø 3.2
10
10
1200
380
608
253
Supply air
duct flange
334
Return air
duct flange
Note
12 groups
all around
