Features of Ducted Split Systems - Medium Static Pressure
Sizes 12K - 18K - 24K - 30K - 36K
Optional drain pump which can lift the
condensate water up to 750 mm upmost.
Optinal drain pump is factory installed
upon request.
750mm
ceiling
Easy and Flexible Installation
Due to compact dimensions, low height and low weight, the installation of ducted indoor unit - medium
static pressure on the ceiling is faster and extremely easy.
Min. 5mm
Drop - Ceiling
210 mm
270 mm
300 mm
Size
Dimensions (mm)
Net Weight
Kg
WHD
12K 920 210 635 23
18K - 24K 920 270 635 28
30K - 36K 1200 300 865 44.5
Low Height
Compact Dimensions & Light Weight
Smart Refrigerant leak detection by sensitive
sensor mounted on indoor coil for easy fast
service and maintenance.
Flexible two directions of air return :
Back air return ( factory standard )
Bottom air return ( can be done at eld ).
Bottom
Return
Air
Back
Return
Air
Pre-Punched Fresh intake air built in the indoor
unit from both sides to make air quality more
healthy and more comfortable.
Fresh air intake
Easy accessibility for motors and fans on indoor
unit for easy fast service and maintenance.
Motor
Bottom
Panel
Blower
housing
Easy removal of washable air lters for cleaning.
ON / OFF
Remote ON / OFF function provides more easy
central ON / OFF control of ducted split system.
Alarm
Remote system alarm function which required
for some applications such as computer rooms
for fast and easy service and maintenance.
Indoor Unit
Main Board
Alarm Output
ALARM
CN33
Indoor Unit
Main Board
CN23
ON / OFF
Remote Control
Ceiling
750 mm
