4
DUCTED SPLIT SYSTEM DESCRIPTION
3.2 Ducted Split System – Medium Static Pressure 36K
1: Supply Air From Indoor Unit
2: Return Air To Indoor Unit
3: Air Filter (s)
4: Electrical Box
5: Condensate Drain Hose
6: Inter-connecting refrigerant piping lines and electrical cables
between outdoor and indoor units.
7: Wired Room Controller ( Standard )
8: Display & Receiver Panel for optional wireless remote control
1
2
3
4
5
6
7
Indoor Unit
Medium Static Pressure
Outdoor Unit
Top Discharge
8
