i-Vu® XT Router (drv_gen5) CARRIER CORPORATION ©2022
Installation and Start-up Guide 10 All rights reserved
Set this port's address ...
In this location...
See...
IP
Service Port
To set the IP address
IPv6
Service Port
To set an IPv6 address (page 13)
Port S1
Service Port
To set the Port S1 address and baud rate (page
15)
Port S2
Service Port
To set the Port S2 address and baud rate (page
15)
To access the controller setup through the Service Port:
1 Connect an Ethernet cable from a computer to the router as shown below.
2 Turn off the computer's Wi-Fi if it is on.
3 If your computer uses a static IP address, use the following settings:
○ Address: 169.254.1.x, where x is 2 to 7
○ Subnet Mask: 255.255.255.248
○ Default Gateway: 169.254.1.1
4 If it uses a DHCP address, leave the address as it is.
5 Open a web browser on the computer.
6 Navigate to http://local.access or http://169.254.1.1 to see the Service Port controller setup pages.
Addressing the i-Vu® XT Router
