SYS (System Status) Tricolor LED
Color
Pattern
Condition
Message in Module
Status
Possible Solution
Red
2 blink
Restarting after an abnormal exit
Auto restart delay due to
system error on startup
After 5-minute delay has
expired, if condition occurs
again then cycle power
Red
4 blink
Firmware image is corrupt
Firmware error
Download driver again
Red
Fast
blink
Firmware error has caused the
firmware to exit and restart
Fatal error detected
No action required
Green
1 blink
No errors
Operational
No action required
Green
2 blink
Download of driver is in progress
Download in progress
No action required
Green
3 blink
BACnet Device ID is not set
Download required
Download the router
Green
Fast
blink
Installation of recently downloaded
driver is occurring
N/A
No action required
Blue
On
Router is starting up
N/A
No action required
Blue
Slow
blink
Linux (operating system) is starting up
N/A
No action required
Blue
Fast
blink
Linux is running but it could not start
the firmware application
N/A
Download driver
Orange
slow
blink
i-Vu® XT Router with drv_gen5 driver is
starting
N/A
No action required
Orange
2 blink
i-Vu® XT Router with drv_gen5 driver
has started but is not yet able to
determine system and network status
N/A
No action required
To get a Module Status report
A Module Status report provides information about the router and verifies proper network communication with the
router. You can get this report:
• In the i-Vu® application—Right-click the router on the navigation tree, then select Module Status.
• In the controller setup interface through the Service Port—Click and select Modstat from the drop-down
list.
See Appendix - Module Status field descriptions (page 43).
