Carrier i-Vu XT Router User Manual

i-Vu® XT Router (drv_gen5) CARRIER CORPORATION ©2022
Installation and Start-up Guide 12 All rights reserved
To set a default IP address
Default IP addressing assigns the following to the router:
• IP address = 192.168.168.x
where x is the setting on the rotary switches in the range from 1 to 253
• Subnet Mask = 255.255.255.0
• Default Gateway = 192.168.168.254
1 Set the router's three rotary switches to a unique address on the network. Set the left rotary switch to the
hundreds digit, the middle switch to the tens digit, and the right switch to the ones digit.
EXAMPLE The switches below are set to 125.
2 On the Connections page, under the Gig-E Port tab > Primary BACnet/IP, select Default IP Address in the
drop-down list for Address Mode.
3 Click .
CAUTION
• If you set the Default IP address on the controller setup Connections page > Gig-E Port tab and then change
the rotary switches, you must do one of the following to correct the IP address in the router:
○ Click .
• Cycle the router's power.
You will then need to correct the IP address in the i-Vu® application using Find Devices and Upload All
Content. See the i-Vu® Help for more information.
NOTE The default address is an intranet address. Data packets from this address are not routable to the Internet.
