Carrier i-Vu XT Router - Page 24

i-Vu® XT Router (drv_gen5) CARRIER CORPORATION ©2022
Installation and Start-up Guide 21 All rights reserved
BACnet System Status
The current state of the router:
Operational
Download in Progress
Download Required
Backup in Progress
Non-Operational
Auto Identity Scheme
• Not Autogenerated—you can enter a specific ID that is unique on the
network.
• Autogenerated—the Device Instance is automatically set. You cannot edit
the field.
Device Instance
Contents and editability depend on your Auto Identity Scheme choice.
Identification
Auto Name Scheme
• Not Autogenerated—you can enter a specific name that is unique on the
network.
• Autogenerated—the Device Name is automatically set as the word "device +
the Device Instance". For example, "device2423911". You cannot edit the
field.
Device Name
Contents and editability depend on your Auto Name Scheme choice.
Location
You can enter an intuitive location for the device in the i-Vu® interface. This will
be the device's display name when discovered through Find Devices.
Description
You can enter an intuitive description for the device in the i-Vu® interface.
Vendor Name
This is autogenerated based on the BACnet vendor ID. It is hardcoded in the
firmware and not editable.
Vendor Identifier
This is autogenerated based on the BACnet vendor ID. It is hardcoded in the
firmware and not editable.
Firmware Revision
The firmware version that is in the BACnet device.
APDU
The following three fields refer to all networks over which the i-Vu® XT Router communicates.
APDU Timeout
How many milliseconds the device will wait before resending a message if no
response is received.
APDU Segment Timeout
How many milliseconds the device will wait before resending a message segment
if no response is received.
Number of APDU Retries
The number of times the device will resend a message.
