Carrier i-Vu XT Router User Manual

i-Vu® XT Router (drv_gen5) CARRIER CORPORATION ©2022
Installation and Start-up Guide 28 All rights reserved
Port S2
Port S2 BACnet/MSTP
Enable for a BACnet/MSTP network.
Auto Generate Network
Number
Autogenerated to have the network number for Port S2 automatically set to a
number equal to ((IP network number + rotary switch address) x 10)+3.
Network Number
The network number is 0 by default. Filled in automatically if Autogenerate
Network Number is checked.
NOTE When downloaded from the i-Vu® application, these numbers match those
set using SiteBuilder.
MAC Address
You set the address for Port S2, which must be unique for the system.
End of Network
Indicates status of the router's End of Net? switch.
Max Master
To increase MS/TP performance, enter the highest address used on the MS/TP
network for a master controller. This number must be less than or equal to 127.
Max Info Frames
This is the maximum number of information messages a controller may transmit
before it must pass the token to the next controller. Valid values are 1 to 255.
TIP Set Max Info Frames to a number in the range 20 to 100 so that the
router does not become a bottleneck for traffic being routed from a high-speed
network to the slower MS/TP network.
APDU Length
The length of a message or message segment that can be accepted by the
BACnet device.
Baud Rate
Set this to a baud rate that all other devices on the MS/TP network are set to.
Select 9600, 19200, 38400, 57600, 76800, or 115200.
