Carrier KJR-12B/DP-E - Summarize; Function Summary

Warning
W
W
arning
arning
Please entrust the distributor or professionals to install
the unit. The installers must have the relevant know-how.
Improper installation performed by the user without perm
ission may cause fire, electric,shock, personal injury or
water leakage.
Delegate
installation
Forbid
Forbid
Usage
Usage
W
arning
arning
Do not spray flammable aerosol to the wire
controller directly. Otherwise, fire may occur.
Do not operate with wet hands or let water enter the wire
controller. Otherwise, electric shock may occur.
2. SUMMARIZE
3. FUNCTION SUMMARY
Usage condition:
Main function:
1. Power supply: 5V DC.
2. Operation temperature:
-15°C(-5°F)~ +43°C(+109°F).
3. Operation humidity: 40%-90%, RH.
1. Connecting to indoor unit by A, B, C,
D, E termina.;
2. Button setting action mode.
3. LCD display.
4. Timer for rest time.
2
