LEGEND NOTE: The presence of an inverter duty motor does not guarantee that
the unit will be provided with a VFD, only 50BVW (VAV) units are pro-
vided with a VFD as standard.
Table 13 — Electrical Data — with Belt Drive Motor, Inverter Duty* (50BVV,W,T)
MODELS
RATED
VOLTAGE
VOLTAGE
MIN/MAX
COMPRESSOR INDOOR FAN MOTOR POWER SUPPLY
QTY
RLA
(EACH)
LRA
(EACH)
MOTOR
HP
MOTOR
QTY
FLA
(EACH)
MIN
CIRCUIT
AMPS
MAX
FUSE/
HACR
034
208-230/3/60 197/253 2 55.8 340 7.5 1 19.4 145.0 200
208-230/3/60 197/253 2 55.8 340 10 1 25.2 150.8 200
208-230/3/60 197/253 2 55.8 340 15 1 37.8 163.4 200
208-230/3/60 197/253 2 55.8 340 20 1 49.0 174.6 225
460/3/60 414/506 2 26.9 173 7.5 1 9.7 70.2 90
460/3/60 414/506 2 26.9 173 10 1 12.6 73.1 100
460/3/60 414/506 2 26.9 173 15 1 18.9 79.4 100
460/3/60 414/506 2 26.9 173 20 1 24.5 85.0 110
575/3/60 518/632 2 23.7 132 7.5 1 7.5 60.8 80
575/3/60 518/632 2 23.7 132 10 1 10.3 63.6 80
575/3/60 518/632 2 23.7 132 15 1 15.1 68.4 90
575/3/60 518/632 2 23.7 132 20 1 19.6 72.9 90
044
208-230/3/60 197/253 4 33.3 239 7.5 2 19.4 180.3 200
208-230/3/60 197/253 4 33.3 239 10 2 25.2 191.9 225
208-230/3/60 197/253 4 33.3 239 15 2 37.8 218.3 250
208-230/3/60 197/253 4 33.3 239 20 2 49.0 243.5 250
460/3/60 414/506 4 17.9 125 7.5 2 9.7 95.5 110
460/3/60 414/506 4 17.9 125 10 2 12.6 101.3 110
460/3/60 414/506 4 17.9 125 15 2 18.9 114.1 125
460/3/60 414/506 4 17.9 125 20 2 24.5 126.7 150
575/3/60 518/632 4 12.8 80 7.5 2 7.5 69.4 80
575/3/60 518/632 4 12.8 80 10 2 10.3 75.0 80
575/3/60 518/632 4 12.8 80 15 2 15.1 85.2 100
575/3/60 518/632 4 12.8 80 20 2 19.6 95.3 110
054
208-230/3/60 197/253 4 48.1 245 7.5 2 19.4 243.2 250
208-230/3/60 197/253 4 48.1 245 10 2 25.2 254.8 300
208-230/3/60 197/253 4 48.1 245 15 2 37.8 280.0 300
208-230/3/60 197/253 4 48.1 245 20 2 49.0 302.7 350
460/3/60 414/506 4 18.6 125 7.5 2 9.7 98.5 110
460/3/60 414/506 4 18.6 125 10 2 12.6 104.3 110
460/3/60 414/506 4 18.6 125 15 2 18.9 116.9 125
460/3/60 414/506 4 18.6 125 20 2 24.5 129.5 150
575/3/60 518/632 4 14.7 100 7.5 2 7.5 77.5 90
575/3/60 518/632 4 14.7 100 10 2 10.3 83.1 90
575/3/60 518/632 4 14.7 100 15 2 15.1 92.8 100
575/3/60 518/632 4 14.7 100 20 2 19.6 102.9 110
064
208-230/3/60 197/253 4 55.8 340 7.5 2 19.4 276.0 300
208-230/3/60 197/253 4 55.8 340 10 2 25.2 287.6 300
208-230/3/60 197/253 4 55.8 340 15 2 37.8 312.8 350
208-230/3/60 197/253 4 55.8 340 20 2 49.0 335.2 350
460/3/60 414/506 4 26.9 173 7.5 2 9.7 133.7 150
460/3/60 414/506 4 26.9 173 10.0 2 12.6 139.5 150
460/3/60 414/506 4 26.9 173 15.0 2 18.9 152.1 175
460/3/60 414/506 4 26.9 173 20.0 2 24.5 163.3 175
575/3/60 518/632 4 23.7 132 7.5 2 7.5 115.7 125
575/3/60 518/632 4 23.7 132 10.0 2 10.3 121.3 125
575/3/60 518/632 4 23.7 132 15.0 2 15.1 130.9 150
575/3/60 518/632 4 23.7 132 20.0 2 19.6 139.9 150
FLA — Full Load Amps
HP — Horsepower
LRA — Locked Rotor Amps
RLA — Rated Load Amps
