Carrier Touch Pilot 30XW-V - Menu Configuration Sections Overview

13

icon   Associated
table
General
Con guration
General con guration GEN_CONF
Pump
Con guration
Pump con guration PUMPCONF
User Con guration User con guration USERCONF
Reset
Con guration
Setpoint reset RESETCFG
Schedule Menu Time schedule SCHEDULE
Holiday Menu Holidays HOLIDAY
Broadcast Menu Broadcast menu BROCASTS
Date/Time
con guration
Date/time con guration DATETIME
Control
Identi cation
Control identi cation CTRL_ID

No. Status  Unit  
1 0 to 2 0 - Cir Priority Sequence Circuit priority
2 0 = Auto, 1 = A Prio 0 = auto, 1 = priority circuit A
3 2 = B Prio 2 = priority circuit B
4 yes/no no - Staged Loading Sequence Staged loading sequence
5 yes/no no - Ramp Loading Select Ramp loading selection
6 1 to 15 1 - Unit O to On Delay Start-up delay
7 0 to 2 0 - Demand Limit Type Select Limitation type selection
8 0 = None 0 = none
9 1 = Switch Control 1 = switch control
10 2 = 4-20 mA Control 2 = 4-20 mA signal control
11 00:00 0 - Night Mode Start Hour Night mode start hour
12 00:00 0 - Night Mode End Hour Night mode end hour
13 - 100 % Night capacity Limit Night mode capacity limit
14 yes/no no - Current Limit select Active limitation selection
15 yes/no no - Ice mode enable Ice storage validation
16 0 to 4000 2000 A Maximum Current Limit Maximum current limit
17 yes/no no - short cycle management Short cycle management (compressor protection)

No. Status   
1 0 to 4 0 Condenser Pump Sequence Condenser pump sequence
2 0 to 4 0 Cooler Pump Sequence Evaporator pump sequence
3 0 = No Pump 0 = No pump
4 1 = One Pump Only 1 = 1 pump
5 2 = Two Pumps Auto 2 = 2 pumps automatic
6 3 = Pump#1 Manual 3 = pump 1 manual
7 4 = Pump#2 Manual 4 = pump 2 manual
8 24 to 3000 48 Pump Auto Rotation Delay Pump rotation delay
9 yes/no no Pump Sticking Protection Pump sticking protection
10 yes/no no Stop Pump During Standby Stop pump when unit is in standby
11 yes/no yes Flow Checked if Pump O Flow check when pump is o
12 yes/no no Cooler pump o in heat Evaporator pump o in heating
13 yes/no no Cond pump o in cool Condenser pump o in cooling
* Depends on selected language, default is English
