7 - DETAILED MENU STRUCTURE
7.1 - Main menu (MAINMEN1)
Icon Displayed text* Description Name
General Parameters General parameters GENUNIT
Temperatures Temperatures TEMP
Pressures Pressures PRESSURE
Inputs Status Inputs status INPUTS
Outputs Status Outputs status OUTPUTS
Modes Modes MODES
Pump Status Pump status PUMPSTAT
Miscellaneous Status Miscellaneous parameters status MSC_STAT
Run Times Run times RUNTIME
DC Free Cooling Status Dry Cooler Free Cooling status DCFC_STA
Air Condenser Status Air Condenser status AIR_COND
Setpoint Table Setpoint settings SETPOINT
Conguration Menu Conguration menu CONFIG1
*Displayed in English by default.
CAUTION: Since specic units may not include additional
features, some tables may contain parameters that cannot
be congured for a given unit.
