General Parameters Menu – GENUNIT
No. Name Status Default Unit Displayed text * Description
1 CTRL_TYP 0 to 2 0 - Local=0 Net.=1 Remote=2 Operating mode:
0 = Local; 1 = Network; 2 = Remote
2 STATUS - - - Run Status Off, Running, Stopping, Delay, Trip out, Ready, Override, etc.
3 CHIL_S_S disable/
enable
disable - Net.: Cmd Start/Stop Unit start/stop via Network: When the unit is in Network mode,
start/stop command can be forced
4 CHIL_OCC no/yes no - Net.: Cmd Occupied Unit time schedule via Network: When the unit is in Network mode,
the forced value can be used instead of the real occupancy state
5 min_left - - min Minutes Left for Start Minutes before the unit start-up
6 HEATCOOL - - - Heat/Cool status Heating/cooling status: Heat/Cool
7 HC_SEL cool/heat - - Heat/Cool Select Heating/cooling selection
8 SP_SEL 0 to 2 0 - Setpoint Select Setpoint selection
9 0=Auto. 1=Spt1. 2=Spt2 0 = Auto (schedule control)
1 = Setpoint 1
2 = Setpoint 2
10 SP_OCC no/yes yes - Setpoint Occupied? Setpoint occupancy status
11 CAP_T 0 to 100 0 % Percent Total Capacity Total unit capacity
12 CAPA_T 0 to 100 0 % Circuit A Total Capacity Total capacity, circuit A
13 CAPB_T 0 to 100 0 % Circuit B Total Capacity Total capacity, circuit B
14 SP - - °C / °F Current Setpoint Current setpoint
15 CTRL_PNT - - °C / °F Control Point Control point: Water temperature that the unit must produce
16 TOT_CURR - - A Actual Chiller Current Actual chiller current
17 CURR_LIM 0 to 2000 0 A Chiller Current Limit Chiller current limit
18 EMSTOP disable/
enable
disable - Emergency Stop Emergency stop: Used to stop the unit regardless of its active
operating type
19 DEM_LIM 0 to 100 0 % Active Demand Limit Val Active demand limit value: When the unit is in Network mode, the
minimum value will be used compared to the status of the external
limit switch contact and the demand limit switch setpoint
*Displayed in English by default.
Temperatures Menu – TEMP
No. Name Status Default Unit Displayed text * Description
1 COOL_EWT - - °C / °F Cooler Entering Fluid Evaporator entering water temperature: Used for capacity control
2 COOL_LWT - - °C / °F Cooler Leaving Fluid Evaporator leaving water temperature: Used for capacity control
3 COND_EWT - - °C / °F Condenser Entering Fluid Condenser entering water temperature: Used for capacity control
4 COND_LWT - - °C / °F Condenser Leaving Fluid Condenser leaving water temperature: Used for capacity control
5 SPACETMP - - °C / °F Optional Space Temp Optional space temperature
6 CHWSTEMP - - °C / °F CHWS Temperature Master/slave temperature
7 CHWSHEAT - - °C / °F CHWS Heat Temp Master/slave heating temperature
8 DGT_A - - °C / °F Discharge Gas Temp cir A Discharge gas temperature, circuit A
9 SCT_A - - °C / °F Saturated Cond Tmp cir A Saturated condensing temperature, circuit A
10 LIQT_A - - °C / °F SubCooling Temp cir A Subcooling temperature, circuit A
11 SLT_A - - °C / °F Saturated Liquid temp A Saturated liquid temperature, circuit A
12 SST_A - - °C / °F Saturated Suction Temp A Saturated suction temperature, circuit A
13 SUCT_A - - °C / °F Compressor Suction Tmp A Compressor suction temperature, circuit A
14 DGT_B - - °C / °F Discharge Gas Temp cir B Discharge gas temperature, circuit B
15 SCT_B - - °C / °F Saturated Cond Tmp cir B Saturated condensing temperature, circuit B
16 LIQT_B - - °C / °F SubCooling Temp cir B Subcooling temperature, circuit B
17 SLT_B - - °C / °F Saturated Liquid temp B Saturated liquid temperature, circuit B
18 SST_B - - °C / °F Saturated Suction Temp B Saturated suction temperature, circuit B
19 SUCT_B - - °C / °F Compressor Suction Tmp B Compressor suction temperature, circuit B
*Displayed in English by default.
7 - DETAILED MENU STRUCTURE
