Pressures Menu – PRESSURE
No. Name Status Default Unit Displayed text * Description
1 DP_A - - kPa / PSI Discharge Pressure A Discharge gas pressure, circuit A
2 LIQP_A - - kPa / PSI SubCooling Pressure A Subcooling pressure, circuit A
3 SP_A - - kPa / PSI Main Suction Pressure A Main suction pressure, circuit A
4 DP_B - - kPa / PSI Discharge Pressure B Discharge gas pressure, circuit B
5 LIQP_B - - kPa / PSI SubCooling Pressure B Subcooling pressure, circuit B
6 SP_B - - kPa / PSI Main Suction Pressure B Main suction pressure, circuit B
*Displayed in English by default.
Inputs Status Menu – INPUTS
No. Name Status Default Unit Displayed text * Description
1 ONOFF_SW open/close open - Remote On/Off Switch Remote On/Off Switch
2 HC_SW open/close open - Remote HeatCool Switch Heating/cooling selection switch
3 SETP_SW open/close open - Remote Setpoint Switch Setpoint selection switch
4 LIM_SW1 open/close open - Limit Switch 1 Capacity limitation switch 1
5 SP_RESET - - mA Reset/Setpnt4-20mA Sgnl 4-20 mA signal, setpoint reset
6 LIM_ANAL - - mA Limit 4-20mA Signal 4-20 mA signal, capacity limitation
7 leak_v - - V Leakage detector 1 val Leak detection input 1
8 leak_2_v - - V Leakage detector 2 val Leak detection input 2
9 REM_LOCK open/close open - Customer Interlock Customer interlock status
10 ICE_SW open/close open - Ice Done Storage Switch Ice storage end switch
11 OCC_OVSW open/close open - Occupied Override Switch Occupied override switch
12 CB_Tmst open/close open - Control Box Thermostat Control box thermostat (if "open", the unit will be stopped in order
to limit heat in the control box)
13 bacdongl no/yes no - BACnet Dongle BACnet dongle
14 HP_SW_A open/close open - High Pressure Switch A High pressure switch, circuit A
15 HP_SW_B open/close open - High Pressure Switch B High pressure switch, circuit B
16 OFA_Fb open/close open - Contactor State Cir A Circuit Contactor state, circuit A
17 OFB_Fb open/close open - Contactor State Cir B Circuit Contactor state, circuit B
*Displayed in English by default.
Outputs Status Menu – OUTPUTS
No. Name Status Default Unit Displayed text * Description
1 CP_A1_PW 0 to 100 0 % Compressor A1 Load Compressor A1 load, circuit A
2 CP_A2_PW 0 to 100 0 % Compressor A2 Load Compressor A2 load, circuit A
3 EXVPosA 0 to 100 0 % EXV Position Circuit A EXV position, circuit A
4 CP_B1_PW 0 to 100 0 % Compressor B1 Load Compressor B1 load, circuit B
5 CP_B2_PW 0 to 100 0 % Compressor B2 Load Compressor B2 load, circuit B
6 EXVPosB 0 to 100 0 % EXV Position Circuit B EXV position, circuit B
7 CAPT_010 0 to 10 0 V Chiller Capacity signal Chiller capacity signal
8 ALARM off/on off - Alarm Relay Status Alarm relay status
9 RUNNING off/on off - Running Relay Status Running relay status
10 ALERT off/on off - Alert Relay State Alert relay status
11 SHUTDOWN off/on off - Shutdown Indicator State Shutdown indicator status
12 pos_3wv 0 to 100 0 % Cond 3 Way Valve Pos Condenser 3-way valve position
13 OFA_Cmd open/close open - Contactor Control Cir A Contactor Command, circuit A
14 OFB_Cmd open/close open - Contactor Control Cir B Contactor Command, circuit B
15 dcfc_vfn 0 to 100 0 % Dcfc varifan speed Dry Cooler Free Cooling, variable speed
16 dcfc_2wv open/close close - Dcfc 2 ways valve Dry Cooler Free Cooling, 2-way valve
17 dcfc_3wv 0 to 100 0 % Dcfc 3 ways valve Dry Cooler Free Cooling, 3-way valve
18 dcfc_f1 off/on off - Dcfc fan stage 1 Dry Cooler Free Cooling, fan stage 1
19 dcfc_f2 off/on off - Dcfc fan stage 2 Dry Cooler Free Cooling, fan stage 2
20 dcfc_f3 off/on off - Dcfc fan stage 3 Dry Cooler Free Cooling, fan stage 3
21 dcfc_f4 off/on off - Dcfc fan stage 4 Dry Cooler Free Cooling, fan stage 4
22 dcfc_f5 off/on off - Dcfc fan stage 5 Dry Cooler Free Cooling, fan stage 5
23 dcfc_f6 off/on off - Dcfc fan stage 6 Dry Cooler Free Cooling, fan stage 6
24 dcfc_f7 off/on off - Dcfc fan stage 7 Dry Cooler Free Cooling, fan stage 7
*Displayed in English by default.
7 - DETAILED MENU STRUCTURE
