Carrier Touch Pilot Control Series User Manual

Modes Menu – MODES
No. Name Status Default Unit Displayed text * Description
1 m_delay no/yes no - Start Up Delay In Effect Start-up delay in effect
2 m_2stpt no/yes no - Second Setpoint In Use Second setpoint in use
3 m_reset no/yes no - Reset In Effect Setpoint reset active
4 m_demlim no/yes no - Demand limit active Demand limit active
5 m_MaxCon no/yes no - Maximum Condens. Limit Maximum condensing limitation active
6 m_MinCoo no/yes no - Minimum Cooling Limit Maximum cooling limitation active
7 m_ramp_l no/yes no - Ramp Limit reached Capacity is limited by ramp logic
8 m_pmpper no/yes no - Pump Periodic Start Periodic cooler pump start-up
9 m_night no/yes no - Night Low Noise Active Night mode active
10 m_slave no/yes no - Master Slave Active Master/slave active
11 m_cpmppr no/yes no - Cond Pump Periodic Start Periodic condenser pump start-up
12 m_ice no/yes no - Ice Mode In Effect Ice storage mode active
*Displayed in English by default.
Pump Status Menu – PUMPSTAT
No. Name Status Default Unit Displayed text * Description
1 SET_FLOW no/yes no - Cooler Flow Setpoint Out Evaporator ow setpoint output
2 CPUMP_1 off/on off - Cooler Pump #1 Command Evaporator pump control command
3 FLOW_SW open/close open - Cooler Flow Switch Cooler ow switch
4 HPUMP_1 off/on off - Condenser Pump
Command1
Condenser pump control command
5 CONDFLOW open/close open - Condenser Flow Status Condenser ow switch
*Displayed in English by default.
Miscellaneous Status Menu – MSC_STAT
No. Name Status Default Unit Displayed text * Description
1 m_ecopmp no/yes no - Eco Pump Mode Active Eco pump mode active (see section 8.8.3)
*Displayed in English by default.
Run Times Menu – RUNTIME
No. Name Status Default Unit Displayed text * Description
1 HR_MACH - - hour Machine Operating Hours Unit operating hours
2 st_mach - - - Machine Starts Number Number of unit starts
3 hr_cpa1 - - hour Compressor A1 Hours Operating hours, compressor A1
4 st_cpa1 - - - Compressor A1 Starts Number of starts, compressor A1
5 hr_cpa2 - - hour Compressor A2 Hours Operating hours, compressor A2
6 st_cpa2 - - - Compressor A2 Starts Number of starts, compressor A2
7 hr_cpb1 - - hour Compressor B1 Hours Operating hours, compressor B1
8 st_cpb1 - - - Compressor B1 Starts Number of starts, compressor B1
9 hr_cpb2 - - hour Compressor B2 Hours Operating hours, compressor B2
10 st_cpb2 - - - Compressor B2 Starts Number of starts, compressor B2
11 hr_cpum1 - - hour Cooler Pump #1 Hours Operating hours, evaporator pump
12 hr_hpum1 - - hour Condenser Pump #1
Hours
Operating hours, condenser pump
