DC Free Cooling Status Menu – DCFC_STA
No. Name Status Default Unit Displayed text * Description
1 oat - - °C / °F OAT Free Cooling Free Cooling / Dry cooler: OAT
2 lwt - - °C / °F FC Leaving Water Temp Free Cooling / Dry Cooler: Leaving water temperature
3 wloop - - °C / °F FC Water Loop Temp Free Cooling / Dry Cooler: Water loop temperature
4 m_dcfc no / yes no - Free Cooling Mode Active Free Cooling mode active
5 dcfc_cap 0 to 100 0 % FC Capacity Free Cooling / Dry Cooler capacity
6 dcfc_al normal /
alarm
normal - DCFC process is in alarm Dry Cooler Free Cooling process failure
7 f_stage 0 to 10 0 - Fans Stage Free Cooling / Dry Cooler fan stage (x-speed fans)
8 vf_speed 0 to 100 0 % Varifan Speed Free Cooling / Dry Cooler: Fan speed (variable-speed fans)
9 pid_out 0 to 100 0 % PID Output Status of PID output
10 FC_HOUR 0 to 999999 0 hour DCFC Operating Hours Free Cooling / Dry cooler: Operating hours
11 FC_FAN1S 0 to 999999 0 - DCFC Fan Stage 1 Start DCFC / Fan stage 1: Number of starts
12 FC_FAN1H 0 to 999999 0 hour DCFC Fan Stage 1 Hours DCFC / Fan stage 1: Operating hours
13 FC_FAN2S 0 to 999999 0 - DCFC Fan Stage 2 Start DCFC / Fan stage 2: Number of starts
14 FC_FAN2H 0 to 999999 0 hour DCFC Fan Stage 2 Hours DCFC / Fan stage 2: Operating hours
15 FC_FAN3S 0 to 999999 0 - DCFC Fan Stage 3 Start DCFC / Fan stage 3: Number of starts
16 FC_FAN3H 0 to 999999 0 hour DCFC Fan Stage 3 Hours DCFC / Fan stage 3: Operating hours
17 FC_FAN4S 0 to 999999 0 - DCFC Fan Stage 4 Start DCFC / Fan stage 4: Number of starts
18 FC_FAN4H 0 to 999999 0 hour DCFC Fan Stage 4 Hours DCFC / Fan stage 4: Operating hours
19 FC_FAN5S 0 to 999999 0 - DCFC Fan Stage 5 Start DCFC / Fan stage 5: Number of starts
20 FC_FAN5H 0 to 999999 0 hour DCFC Fan Stage 5 Hours DCFC / Fan stage 5: Operating hours
21 FC_FAN6S 0 to 999999 0 - DCFC Fan Stage 6 Start DCFC / Fan stage 6: Number of starts
22 FC_FAN6H 0 to 999999 0 hour DCFC Fan Stage 6 Hours DCFC / Fan stage 6: Operating hours
23 FC_FAN7S 0 to 999999 0 - DCFC Fan Stage 7 Start DCFC / Fan stage 7: Number of starts
24 FC_FAN7H 0 to 999999 0 hour DCFC Fan Stage 7 Hours DCFC / Fan stage 7: Operating hours
25 FC_VFANS 0 to 999999 0 - DCFC Variable Fan Start DCFC / Variable-speed fan: Number of starts
26 FC_VFANH 0 to 999999 0 hour DCFC Variable Fan Hours DCFC / Variable-speed fan: Operating hours
*Displayed in English by default.
Air Condenser Status Menu – AIR_COND
No. Name Status Default Unit Displayed text * Description
1 oat - - °C / °F Outdoor Air Temperature Outdoor air temperature
2 Dry Cooler Status Status of the Dry Cooler connected on the condenser side
3 DC_LWT - - °C / °F Leaving Water Temp Leaving water temperature
4 DC_FanSt - - - Runing Fan Stages Running fan stages
5 DC_FanSp - - % Variable Speed Variable Speed
6 Air Condensing Status of the air condenser connected to the refrigerant circuits
7 FanSt_A - - - Circuit A Fan Stages Circuit A Fan Stages
8 FanSp_A - - % Variable Speed Fan A Variable-speed Fan, circuit A
9 FanSt_B - - - Circuit B Fan Stages Circuit B Fan Stages
10 FanSp_B - - % Variable Speed Fan B Variable-speed Fan, circuit B
11 Runtime Runtime
12 COND_F1S - - - Condensing Fan 1 Start Condensing fan 1: Number of starts
13 COND_F1H - - hour Condensing Fan 1 Hours Condensing fan 1: Operating hours
14 COND_F2S - - - Condensing Fan 2 Start Condensing fan 2: Number of starts
15 COND_F2H - - hour Condensing Fan 2 Hours Condensing fan 2: Operating hours
16 COND_F3S - - - Condensing Fan 3 Start Condensing fan 3: Number of starts
17 COND_F3H - - hour Condensing Fan 3 Hours Condensing fan 3: Operating hours
18 COND_F4S - - - Condensing Fan 4 Start Condensing fan 4: Number of starts
19 COND_F4H - - hour Condensing Fan 4 Hours Condensing fan 4: Operating hours
20 COND_F5S - - - Condensing Fan 5 Start Condensing fan 5: Number of starts
21 COND_F5H - - hour Condensing Fan 5 Hours Condensing fan 5: Operating hours
22 COND_F6S - - - Condensing Fan 6 Start Condensing fan 6: Number of starts
23 COND_F6H - - hour Condensing Fan 6 Hours Condensing fan 6: Operating hours
24 COND_F7S - - - Condensing Fan 7 Start Condensing fan 7: Number of starts
25 COND_F7H - - hour Condensing Fan 7 Hours Condensing fan 7: Operating hours
26 COND_F8S - - - Condensing Fan 8 Start Condensing fan 8: Number of starts
27 COND_F8H - - hour Condensing Fan 8 Hours Condensing fan 8: Operating hours
28 CirA_VFS - - - Cond VariFan CirA Start Condensing variable-speed fan (circuit A): Number of starts
29 CirA_VFH - - hour Cond VariFan CirA Hour Condensing variable-speed fan (circuit A): Operating hours
30 CirB_VFS - - - Cond VariFan CirB Start Condensing variable-speed fan (circuit B): Number of starts
31 CirB_VFH - - hour Cond VariFan CirB Hour Condensing variable-speed fan (circuit B): Operating hours
*Displayed in English by default.
