Carrier Touch Pilot Control Series - Setpoint Table Menu

7 - DETAILED MENU STRUCTURE
Setpoint Table Menu – SETPOINT
No. Name Status Default Unit Displayed text * Description
1 csp1 -28.9 to 26.0
-20 to 78.8
6.7
44
°C
°F
Cooling Setpoint 1 Cooling setpoint 1 (used during occupied periods)
2 csp2 -28.9 to 26.0
-20 to 78.8
6.7
44
°C
°F
Cooling Setpoint 2 Cooling setpoint 2 (used during unoccupied periods)
3 ice_sp -28.9 to 26.0
-20 to 78.8
6.7
44
°C
°F
Cooling Ice Setpoint Cooling ice setpoint
4 cramp_sp 0.11 to 11.11
0.2 to 20
0.6
1
^C
^F
Cooling Ramp Loading Cooling ramp loading setpoint (rate at which the water temperature
may change within one minute)
5 hsp1 26.7 to 63.0
80 to 145.4
37.8
100
°C
°F
Heating Setpoint 1 Heating setpoint 1 (used during occupied periods)
6 hsp2 26.7 to 63.0
80 to 145.4
37.8
100
°C
°F
Heating Setpoint 2 Heating setpoint 2 (used during unoccupied periods)
7 hramp_sp 0.11 to 11.11
0.2 to 20
0.6
1
^C
^F
Heating Ramp Loading Heating ramp loading setpoint (rate at which the water temperature
may change within one minute)
8 w_sct_sp 26.67 to 48.89
80 to 120
35
95
°C
°F
Water Val Condensing Stp Condensing setpoint
9 lim_sp1 0 to 100 100 % Switch Limit Setpoint 1 Demand limit setpoint 1
10 lim_sp2 0 to 100 100 % Switch Limit Setpoint 2 Demand limit setpoint 2
11 lim_sp3 0 to 100 100 % Switch Limit Setpoint 3 Demand limit setpoint 3
*Displayed in English by default.
21
