ZS duct sensors
ZS Sensors Carrier Proprietary and Confidential CARRIER CORPORATION ©2017
Installation Guide All rights reserved
16
Duct Temperature Sensor
Available with:
• 4 in. (10.16 cm) probe
• 8 in. (20.32 cm) probe
• Back or bottom probe *
Duct Temperature/Humidity Sensor
Available with:
• 5.3 in. (13.5 cm) probe
• Back or bottom probe *
Duct Temperature Averaging Sensor
Available with:
• 8 ft (2.44 m) flexible probe
• 12 ft (3.66 m) flexible probe
• 24 ft (7.32 m) flexible probe
• Back or bottom probe *
* Sensors with back probes (as shown) are to be mounted on the outside of ductwork.
Sensors with bottom probes are to be mounted on the inside of ductwork.
