7.2 MIDI Patch Configuration
The Quad X-Amp is setup with a pre-defined MIDI Patch configuration that defines which
Quad X-Amp channel will be selected for each of the 1-128 MIDI Patch calls. This
configuration has been setup to offer you the maximum flexibility in your system. Patches 1-65
advance in a sequential pattern, (CH1,CH2,CH3,CH4,CH4) this allows the Quad X-Amp
Channel 1 to be accessible by the first patch in each bank of ten on your MIDI footswitch.
Patches 66-128 advance in blocks of five (Patches 66-70 are CH1, Patches 71-75 = CH2 and so
on) this allows you to configure your effects units around the individual Quad X-Amp channels.
To see exactly which Channel is selected by which MIDI Patch call refer to the table below.
Quad X-Amp MIDI Channel Selection Chart
1 1 33 3 65 4 97 3
2 2 34 4 66 1 98 3
3 3 35 4 67 1 99 3
4 4 36 1 68 1 100 3
5 4 37 2 69 1 101 4
6 1 38 3 70 1 102 4
7 2 39 4 71 2 103 4
8 3 40 4 72 2 104 4
9 4 41 1 73 2 105 4
10 4 42 2 74 2 106 1
11 1 43 3 75 2 107 1
12 2 44 4 76 3 108 1
13 3 45 4 77 3 109 1
14 4 46 1 78 3 110 1
15 4 47 2 79 3 111 2
16 1 48 3 80 3 112 2
17 2 49 4 81 4 113 2
18 3 50 4 82 4 114 2
19 4 51 1 83 4 115 2
20 4 52 2 84 4 116 3
21 1 53 3 85 4 117 3
22 2 54 4 86 1 118 3
23 3 55 4 87 1 119 3
24 4 56 1 88 1 120 3
25 4 57 2 89 1 121 4
26 1 58 3 90 1 122 4
27 2 59 4 91 2 123 4
28 3 60 4 92 2 124 4
29 4 61 1 93 2 125 4
30 4 62 2 94 2 126 1
31 1 63 3 95 2 127 1
32 2 64 4 96 3 128 1
Quad X-Amp Using the Quad X-Amp MIDI Section 7
MIDI
PATCH
MIDI
PATCH
MIDI
PATCH
MIDI
PATCH
QUAD X
Channel
QUAD X
Channel
QUAD X
Channel
QUAD X
Channel
7-2
