Quad X-Amp Technical Specifications Appendix A
A-1
Technical Specifications of the Quad X-Amp Preamp
Frequency Response 20 to 20kHz ±3 dB (fixed EQ defeated)
Total Harmonic Distortion less than .05%
Sound Quality Totally Outrageous!
EQ Centers
Three Band (Ch 1 &4) 80, 500, 3kHz
Two Band (Ch 2 &3) 80, 3kHz
Graphic EQ 75, 150, 1K, 3k, 6kHz
Nominal Line Output 0 dBV (.775 Vrms)
Maximum Line Output +22 dBV
Power Requirements 120/240 VAC, 50-60 Hz
Warranty One year parts and labor
Dimensions and Weight 19” W x 10” D x 3.5” H 15lbs.
