CAS PB Series Service Manual

11
Service Manual
–
PB
Series
REV NO
:
2
5.2. Error Message
오류
오류오류
오류 종류
종류종류
종류(ERR ? )
(ERR ? )(ERR ? )
(ERR ? ) 원인
원인원인
원인(REASONS)
(REASONS)(REASONS)
(REASONS) (SOLUTI
(SOLUTI(SOLUTI
(SOLUTION)
ON)ON)
ON)
"Err 0"
The "Err 0" occurs when scale is not
stable.
Remove unstable facts.
"Err 1"
The "Err 1" occurs when a current zero
point has shifted from the last span
calibration.
Please call your CAS dealer.
"Err 2"
The "Err 2" is not a real error. Only it
prompts return CAL switch to the
normal position.
Please call your CAS dealer.
"Err 3"
The "Err 3" is an overload error. Please remove the weight.
"Err 9"
The "Err 9" is no weight error. When
scale is in counting mode, you must
load the weight.
If you have no weight on your scale,
you can see this error message.
Please load the weight on your tray.
“Err 11”
The "Err 11" means a writing error of
the internal nonvolatile memory. To
recognize this error, be sure to check
the voltage on the circuit and do
calibration procedures.
If it still has "Err 11", replace the digital
module.
“Err 12”
The "Err 12" warns that the scale has
lost the parameters for weighing
regulations or has lost the factors for a
digital span calculation.
Enter each condition codes again.
Please try a span calibration again if
still not fixed.
“Err 14”
The "Err 14" means calibration range is
not correct.
Please call your CAS dealer.
6. Options Installing
6.1. Serial Interface(RS-232C)

CAS PB Series Specifications

General

Display	LCD
Overload Protection	Yes
Units	g, oz
Interface	RS-232 (optional on some models)
Auto Calibration	Yes
Operating Temperature	10°C to 40°C
Material	Stainless steel platform, ABS housing
