CAS PB Series Service Manual

6
Service Manual
–
PB
Series
REV NO
:
2
4. Calibration Mode
4.1. General Calibration
Pressing and holding calibration switch press [POWER] key to go to calibration mode.
User can move to other mode by using [ZERO] key in the calibration mode.
User also moves to other sub-modes for each mode by using [TARE] key.
Please simply follow below procedure to move to other mode.
(1) Calibration Mode: Pressing and holding “ Calibration Switch ” press [POWER] key.
(2) It displays “ CAL-0 ” after “ CAL ” , and it blinks the version of scale three times.
(3) Selecting menu: press [TARE].
(4) ENTER(Setting) : [TARE] key
MODE Function
CAL 1
Display normalized AD
CAL 2
Display Keypad infomation-
CAL 3
Weight Setting Mode
“UnLoad” [TARE] → →
“MIDD” [TARE] after loading for 1/3 weight → →
“FULL” [TARE] after loading for Full weight → →
“MIDD” [TARE] after loading for 1/3 weight “END” → →
CAL 4
Option Setting ( Refer to Table 1)
CAL 5
Display filtered Raw AD
CAL 7
% Calibration
CAL 8
Battery calibration
CAL 9
Gravity constant
CAL 10
Set calibration factor
“Unit”  [TARE]  select 0, 1 (0:kg, 1: lb)  [TARE]
“CAPA”  [TARE]  select capacity  [TARE]
“MCAPA”  [TARE]  select mid-capacity  [TARE]
“W-dP”  [TARE]  Select Decimal Point  [TARE]
“ 1 d ”  [TARE]  Select division  [TARE]
“Dual”  [TARE]  Enable dual interval (0:disable, 1:enable)  [TARE]
“tare”  [TARE]  Enable custom tare (0:disable, 1:enable)  [TARE]
CAL 11
Set nation(00 : OIML , 01 : NTEP , 02: KOREA)
