OPERATION
DATA PORTS
25-Pin Port
The RS485 data port, located on the back of the oven, connects to the oven temperature controller.
The port is primarily intended for updating the controller software but can be used for data logging
and graphical profile programming. Accessing the controller with a computer requires a 25-pin
RS485-to-USB converter cable and driver software.
Applications and Utility Software
• National Instrument LabView and Watlow SpecView — Temperature monitoring and data
logging in graphical user interface environments.
• Watlow’s EZ Zone™ Configurator — Programming heating profiles in a drop-down menu
environment. Configurator can also be used to copy and save the controller configuration
file, which includes the currently programmed heating profiles.
o Configurator is available for free on the Watlow website.
9-Pin Port
This port connects with accessories ordered from the oven manufacturer, including data loggers.
