— 1 —
1. SPECIFICATIONS
1-1.Electricalspecications
• Power consumption
In operation Max.
120 V 220 V 230 V 240 V
0.1 A 0.05 A 0.05 A 0.05 A
• Memory protection Back-up battery
Back-up period
Battery life
Mangan Battery (UM-3×3 pcs)
1 year (25 °C)
Replace the battery every 1 years.
• Clock & Calendar Accuracy
Auto calendar
Within ± 30 sec. per month (25 °C)
Effective until 2099 A.D.
1-2.Environmentalspecications
• Operating temperature 0 °C ~ 40 °C
• Operating humidity 10 % ~ 95 %
• Storage temperature -25 °C ~ 65 °C
• Storage humidity 10 % ~ 95 %
• Vibration strength 1.5 G (The machine must be in the carton box)
1-3.Maincomponents
• CPU Name
Number of control bit
UPD780058BGC179-8BTA
8 bit
• Thermal printer Name
Print method
MCBF
M-42V-009-040
Print wheel selecting type serial printer
700,000 lines
• Roll paper Type
Size
Roll diam
Fine-quality paper
28 +0/-1 mm
80 mm or less
1-4. Drawer List
Type DrawerName Specication
S DL-1334 D-21L2C-D53RM-4
S DL-1843 D-21LC2-D54RM-4
M DL-2812 D-25L2C-B84RM-4
