Casio 140CR-272 - Final Assy; U-Case Assy

— 28 —
1 140CR-MB
2 140CR-MBUA
3 140CR-MBUG
4 140CR-MBUK
5 140CR-SB
6 140CR-SBUA
7 140CR-SBUG
8 140CR-SBUK
9 140CR-SC
10 140CR-SD
11 140CR-T
12 PCR-272
123456789101112
N Item Part No. Part Name Descriptions
QUANTITY
Price
Code
R
CNBTA1 CONNECTOR/BATTERY 5267-02A-X 111111111111
CNKEY1 CONNECTOR/KEY IMSA-9604S-21C 111111111111
CNDRW1 CONNECTOR/DRAWER IL-G-2P-S3T2-SA 111111111111
BZ1 10241792 BUZZER AW1S22TEP-251Z 111111111111AGC
F1 10201542 FUSE 0239.800MXP 1 1 1 AB A
F1 FUSE 0218.630MXP 11111111 1 A
10195665 CLIP/FUSE FC51F 222222222222AAA
TRANSFORMER TE-264-E1U 11111111 1 C
TRANSFORMER TE-264-E2D 1 1 1 C
10195671 CN SUB ASSY RJE501362*001 1 1 1 AD C
10195669 SWITCH ASSY RJE501360*001 1 1 1 1 1 1 1 BH B
10195672 WIRE SUB ASSY RJE501364*001 111111111111AAC
10195673 WIRE SUB ASSY RJE501364*002 111111111111AAC
SCREW WS 3 X 10 ZC 222222222222
SCREW BA 3 X 8 ZC 222222222222
2. FINAL ASSY
2
10326707 COVER/BATTERY RJE500211-001V03 111111111111ABC
3
10326709 PULLY/WIND RJE501880-001V03 111111111111AEA
4
10285007 SPOOL/PAPER RJE502545-001V01 111111111111ABA
5
10254924 SUBASSY/KEY SET RJE500074*002V03 11111111 11 AJC
5
10325051 SUBASSY/KEY SET RJE503007*003V01 1 1 AD C
6
10325052 BOARD/DISPLAY RJE502996-001V01 1 AT C
6
BOARD/DISPLAY RJE502996-002 11111111111 C
7
10325053 COVER/PRINTER RJE502997-001V01 111111111111ANC
8
10236319 CUTTER/PAPER E441364-003V02 111111111111ABC
9
10331637 SUBASSY/TRAY RJE503185*001V01 1111 AXC
9
10325056 SUBASSY/TRAY RJE503008-001V01 11111111AHC
10
10233584 SEPARATER/BILL RJE500103-001V02 1 1 AH C
S1
SCREW S-BDST-3X8ZC 111111111111
S2
SCREW S-PASEST-3X6Z3 111111111111
SCREW S-PAST-4X8ZC 11111111 11
WASHER W-ET-4Z3 11111111 11
3. U-CASE ASSY
11
10325045 CASE/UPPER RJE502995-001V01 111111111111 BLC
12
10325046 MOUNT/PRINTER RJE503000-001V01 111111111111AEC
13
10325047 HOLDER/PCB/L RJE503002-001V01 111111111111ABC
14
10325048 HOLDER/PCB/R RJE503003-001V01 111111111111ABC
15
10328981 SUBASSY/BAT-CN RJE503038*001V01 111111111111ACC
16
63452238 SPRING/BATTERY/G55 A42606B-1 111111111111AAC
17
10294940 SPRING/BATTERY/G67E RJE502622-001V01 111111111111AAC
18
10325049 SPRING/BATTERY/B-1E RJE502621-001V01 111111111111AAC
19
10294939 SPRING/BATTERY/B-2E RJE502620-001V01 111111111111AAC
20
10224253 CODE/POWER M2511-LF 1111 AZC
20
10225548 CODE/POWER X-AU10S3-LF 1 1 BB C
20
10224252 CODE/POWER MP5004-LF 1 1 1 BG C
20
10240732 CODE/POWER ME301-LF 1 1 AZ C
20
10240731 CODE/POWER TW15CS3-LF 1 BS C
21
10193549 SHEET/INS RJE501394-001V01 111111111111AAC
22
10334571 ASSY/MODE KEY TK-E341249*004V01 111111111111AQC
23
10325050 TABLE/W-E260BK RJE502999-001V01 111111111111AAC
24
10259121 PRINTER M-42V-009-040ROB 11111111 11 CDA
24
10259116 PRINTER M-42V-001-060MAROB 1 1 CB A
S2
SCREW S-BDST-3X8ZC 222222222222
S3
SCREW S-BDPT-3X8ZC 666666666666
S4
SCREW S-WLPT-3X12Z3 444444444444
