3. DISASSEMBLY
Make sure to use correct Screws when assembling since
there are several kinds of them. It is a good idea to sort
them as shown in the right when disassembling.
A. Removing the UPPER CASE block
B. MODE-KEY-SW-ASSY
D. MAIN PCB, PRINTER UNIT and MOTOR
E. KEY-BOARD-ASSY
F. Removing the DRAWER CASE
C. 7 SEGMENT LCD
Disassembly Procedure
Disassemble the main units in the sequence shown below.
