— 5 —
A. Removing the UPPER CASE block
A-1. Remove the printer cover.
A-2. Remove two screws.
A-3. Remove the UPPER CASE.
Screw (S2)Screw (S1)
A-4. Remove the drawer cable.
UPPER CASE
Drawer
Drawer cable
Tape
ASSEMBLING TIPS:
When assembling the UPPER CASE, be sure to x the drawer cable with tape.
Drawer cable
