160
(2) Group name input
The following screen appears on both the parent unit and the duplicate. Input the same group
name to pair between terminals. Input any arbitrary group name (such as 1234) and press the Start
button to automatically search for counterpart terminals and connect with them (automatic pairing).
Now advance to the Standby screen.
No. Item Operation Key operation
1
“Group name“
Specify the group name. -
2
“Start“ button
The terminal starts receiving data as the
duplicate, and transitions to the Receive screen.
Press the F4
key
3
“<< Back“ button
Return to the previous screen. Press the F1
key
4
“Exit“ button
Closes this tool -
(3) Standby screen
The following Standby screen is displayed once the group name is input and the Enter key
pressed.
Parent unit status: Searching CASIO_Group name
Duplicate status Waiting for connection …
