Casio Exilim EX-Z300 - General Guide

152
Appendix
The numbers in parentheses indicate the pages where each item is explained.
. Camera
. Charger Unit
General Guide
1
Shutter button (page 18)
2
[ON/OFF] (Power)
(page 17)
3
Flash (page 28)
4
½ (Make-up) (page 46)
5
Front lamp
(pages 20, 66, 69)
6
Microphone
(pages 47, 99)
7
Lens
8
Zoom controller
(pages 18, 43, 81, 82)
9
Back lamp
(pages 17, 18, 28)
bk
[0] (movie) button
(page 47)
bl
[r] (REC) button
(pages 17, 18)
bm
Strap hole (page 2)
bn
Connector cover
bo
USB/AV port (pages
83, 103, 110, 119)
bp
[SET] button (page 24)
bq
[BS] button (page 52)
br
[MENU] button
(page 61)
bs
Control button
([8][2][4][6])
(page 24)
bt
[p] (PLAY) button
(pages 17, 21)
ck
Monitor screen
(pages 137, 153)
21
7
6
45
3
89 bk
bl
bqbrbsbtck bp bnbmbo
[ ]
[ ]
[ ]
[ ]
[
SET
]
Front Back
cl
Battery/memory card slots (pages 12, 15, 147, 149)
cm
Tripod hole
Use this hole when attaching to a tripod.
cn
Speaker
clcmcn
Bottom
3
2
1
1
+- Contacts
2
[CHARGE] Lamp
3
AC jack
