130
Dynamic Photo
3. If you are inserting a subject into a movie an
image will appear on the monitor screen
showing the approximate location of the
subject in the movie. Use [4] and [6] to shift
the location to the position you want. After you
are finished, press [SET].
If you insert a subject into a movie, the resulting movie will be a maximum of
20 seconds long. Everything before and after the insertion is cut off. If the
movie you are inserting into (original movie) is shorter than 20 seconds, the
resulting movie will be the same length as the original movie.
If you are inserting a subject into a snapshot, skip directly to step 4.
4. Use the zoom controller to adjust the size of the subject and use [8],
[2], [4], and [6] to adjust its position.
5. When everything is the way you want, press [SET].
This inserts the subject into another image and creates a Dynamic Photo.
Inserting an animated subject into a snapshot will save a Dynamic Photo that
consists of 20 still images of 2M size or smaller.
Inserting a subject into a movie will save the Dynamic Photo as a movie file.
NOTE
Performing a delete or format operation will not delete the built-in subjects.
1. Press [p] (PLAY) and then use [4] and [6] to display the Dynamic
Photo you want to view.
2. If you want to see the subject in the Dynamic Photo movie, press [SET].
The Dynamic Photo is repeated as a continuous loop.
Movement of the subject also will start automatically about two seconds after
you display a Dynamic Photo.
To view a Dynamic Photo (Dynamic Photo File)
Insert location

Table of Contents

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Casio EXILIM EX-ZR300 and is the answer not in the manual?

Casio EXILIM EX-ZR300 Specifications

General IconGeneral
Megapixel16.1 MP
Camera typeCompact camera
Sensor typeCMOS
Image stabilizerNo
Total megapixels16.79 MP
Image sensor size1/2.3 \
Supported aspect ratios3:2, 16:9
Maximum image resolution4608 x 3456 pixels
Still image resolution(s)640 x 480, 2048 x 1536, 2560 x 1920, 3648 x 2736, 4608 x 2592, 4608 x 3072
Digital zoom4 x
Optical zoom12.5 x
Combined zoom199.3 x
Focal length range4.24 - 53 mm
Maximum aperture number7.9
Minimum aperture number3
Lens structure (elements/groups)8/9
Maximum focal length (35mm film equiv)300 mm
Minimum focal length (35mm film equiv)24 mm
Normal focusing range0.05 - ∞ m
Auto focusing (AF) modesMulti Point Auto Focus, Spot Auto Focus, Tracking Auto Focus
Macro focusing range (wide)0.01 - 0.5 m
Light meteringCentre-weighted, Evaluative (Multi-pattern)
ISO sensitivity80, 100, 200, 400, 800, 1600, 3200
Light exposure modesAperture priority AE, Manual, Shutter priority AE
Light exposure controlProgram AE
Light exposure correction± 2EV (1/3EV step)
Camera shutter typeElectronic, Mechanical
Fastest camera shutter speed1/4000 s
Slowest camera shutter speed4 s
Flash modesAuto, Red-eye reduction
Flash range (tele)0.9 - 2.4 m
Flash range (wide)0.4 - 4.7 m
Flash recharging time5 s
Built-in flashYes
Power source typeAC
Dimensions (WxDxH)104.8 x 28.6 x 59.1 mm
Video resolutions640 x 480, 1280 x 720, 1920 x 1080 pixels
Motion JPEG frame rate30 fps
Video formats supportedAVCHD, H.264, MOV
Maximum video resolution1920 x 1080 pixels
Internal memory52.2 MB
Compatible memory cardsSD, SDHC, SDXC
Maximum memory card size16 GB
Display diagonal3 \
Display resolution960 x 480 pixels
Display resolution (numeric)460800 pixels
USB version2.0
Product colorWhite
Scene modes-
White balanceAuto, Daylight, Manual, Shade
Camera playbackMovie
Self-timer delay2, 10 s
Camera file systemDCF 2.0, DPOF 1.1, Exif 2.3
Battery typeNP-130
Battery life (CIPA standard)500 shots
Cables includedUSB
Weight and Dimensions IconWeight and Dimensions
Depth28.6 mm
Width104.8 mm
Height59.1 mm
Weight165 g
Weight (including battery)205 g
