Page #35 background imageLoading...
Page #35 background image
35
Quick Start Basics
1. Press [p] (PLAY) to enter the PLAY mode and then press [2] ( ).
2. Use [8] and [2] to select “Delete All Files” and then press [SET].
3. Use [8] and [2] to select “Yes” and then press [SET] to delete all files.
This will cause the message “There are no files” to appear.
Operation
Never open the battery cover while the back lamp is flashing green. Doing so can
result in the image you just shot being saved incorrectly, damage to other images
stored in memory, malfunction of the camera, etc.
If unwanted light is shining onto the lens, block the light with your hand.
Monitor Screen when Shooting Snapshots
Subject brightness conditions can cause monitor screen response to slow and can
cause digital noise in the monitor screen image.
The image that appears on the monitor screen is for image composition. The actual
image will be recorded at the quality set for the image quality setting (page 99).
Shooting Indoors under Fluorescent Lighting
Minute flickering of fluorescent lighting can affect the brightness or color of an
image.
Other Precautions
The slower the shutter speed, the greater the possibility that noticeable noise will
be generated in an image. Because of this, the camera automatically performs a
noise reduction at slow shutter speeds. The noise reduction process causes it to
take longer to record images at lower shutter speeds. The shutter speeds for which
noise reduction is performed depend on the camera setup and shooting conditions.
A noise reduction process is performed when ISO sensitivity is set to a high value.
This can cause the camera to take relatively longer to be ready to shoot again after
you press the shutter button. Do not perform any key operation while the image
recording operation is in progress.
Due to the characteristics of the imaging element used by the camera, very fast
moving objects in an image may appear distorted.
To delete all files
Snapshot Shooting Precautions

Table of Contents

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Casio EXILIM EX-ZR300 and is the answer not in the manual?

Casio EXILIM EX-ZR300 Specifications

General IconGeneral
Megapixel16.1 MP
Camera typeCompact camera
Sensor typeCMOS
Image stabilizerNo
Total megapixels16.79 MP
Image sensor size1/2.3 \
Supported aspect ratios3:2, 16:9
Maximum image resolution4608 x 3456 pixels
Still image resolution(s)640 x 480, 2048 x 1536, 2560 x 1920, 3648 x 2736, 4608 x 2592, 4608 x 3072
Digital zoom4 x
Optical zoom12.5 x
Combined zoom199.3 x
Focal length range4.24 - 53 mm
Maximum aperture number7.9
Minimum aperture number3
Lens structure (elements/groups)8/9
Maximum focal length (35mm film equiv)300 mm
Minimum focal length (35mm film equiv)24 mm
Normal focusing range0.05 - ∞ m
Auto focusing (AF) modesMulti Point Auto Focus, Spot Auto Focus, Tracking Auto Focus
Macro focusing range (wide)0.01 - 0.5 m
Light meteringCentre-weighted, Evaluative (Multi-pattern)
ISO sensitivity80, 100, 200, 400, 800, 1600, 3200
Light exposure modesAperture priority AE, Manual, Shutter priority AE
Light exposure controlProgram AE
Light exposure correction± 2EV (1/3EV step)
Camera shutter typeElectronic, Mechanical
Fastest camera shutter speed1/4000 s
Slowest camera shutter speed4 s
Flash modesAuto, Red-eye reduction
Flash range (tele)0.9 - 2.4 m
Flash range (wide)0.4 - 4.7 m
Flash recharging time5 s
Built-in flashYes
Power source typeAC
Dimensions (WxDxH)104.8 x 28.6 x 59.1 mm
Video resolutions640 x 480, 1280 x 720, 1920 x 1080 pixels
Motion JPEG frame rate30 fps
Video formats supportedAVCHD, H.264, MOV
Maximum video resolution1920 x 1080 pixels
Internal memory52.2 MB
Compatible memory cardsSD, SDHC, SDXC
Maximum memory card size16 GB
Display diagonal3 \
Display resolution960 x 480 pixels
Display resolution (numeric)460800 pixels
USB version2.0
Product colorWhite
Scene modes-
White balanceAuto, Daylight, Manual, Shade
Camera playbackMovie
Self-timer delay2, 10 s
Camera file systemDCF 2.0, DPOF 1.1, Exif 2.3
Battery typeNP-130
Battery life (CIPA standard)500 shots
Cables includedUSB
Weight and Dimensions IconWeight and Dimensions
Depth28.6 mm
Width104.8 mm
Height59.1 mm
Weight165 g
Weight (including battery)205 g
